ABB IDDRPM25606 AC Motor - 60 HP, 460V, CCSA US UR
Part Number: 7BIDDRPM25606
Quick Summary
ABB IDDRPM25606 AC Motor is a robust 3-phase motor designed for continuous-duty operation across manufacturing and process automation environments. Engineers often struggle with unplanned downtime, inconsistent performance, and long procurement cycles; this model addresses those challenges with a laminated frame and rapid stock availability. It carries critical certifications such as CCSA US and UR, and aligns with NEMA standards to support diverse installations. With a 60 HP rating at 460 V and a DPFV enclosure, it delivers reliable power for scalable automation while enabling faster procurement and predictable maintenance schedules.
Product Information
Extended Description
7BIDDRPM25606 ABB: AC VS Laminated Frame - RPMAC 60 Hp 460 V (IDDRPM25606)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
60HP,1150,460V,RL2578,DPFV,F1
Ambient Temperature
40 °C
Base Speed
1200 r/min
Bearing
65BC03JPP30A, Ball
Bearing NDE
50BC03JPP30A
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDDRPM25606
Certification Agency
CCSA US | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Design
A
Dimension Diagram
616779-050
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Electrical Data
Enclosure Type
DPFV
Frame Material
Laminated
Frame Size
2578
Frequency (f)
40 Hz
Global Commercial Alias
IDDRPM25606
Gross Weight
247.208 kg
Horsepower Rating UL/CSA
60.000 Hp
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
Insulation Class
H
Invoice Description
60HP,1150,460V,RL2578,DPFV,F1
Made To Order
No
Medium Description
AC VS Laminated Frame - RPMAC, 60 HP, 1200//1000 RPM, Frame Size Rl2578, Standard Mounting, 3 Phase, DPFV Enclosure, 460 V, (IDDRPM2
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
RL2578
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
3
Number of Poles (High)
6
Order Multiple
1 piece
Output Power
60 Hp
Product Name
AC VS Laminated Frame - RPMAC
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
247.208 kg
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
73 A
Rated Speed
1150 r/min | 1300 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
2.12 in
Shaft Grounding
Shaft Grounding
Short Description
60 HP, 1200//1000 RPM, Frame Size Rl2578, Standard, 3 PH, DPFV, 460 V
Standards
NEMA
Stocked At (Warehouses)
Menden, Germany | China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
460 V
Feature: Laminated RL2578 frame construction delivers superior heat dissipation. Business Impact: Enables higher continuous duty without overheating, reducing insulation stress and bearing wear. Application: Ideal for conveyors, pumps, and mixers in demanding automation lines. Feature: DPFV enclosure provides robust environmental protection. Business Impact: Increases equipment reliability on harsh factory floors and reduces enclosure-related maintenance. Application: Suitable for process industries and packaging lines requiring durable protection. Feature: High power density (60 HP, 460 V, 3-phase, 73 A) with 1200 r/min synchronous speed. Business Impact: Improves throughput and energy efficiency, supporting high-load applications with lower operating costs. Application: Large-scale conveyors, pump systems, and fans in continuous operation. Feature: Laminated frame durability paired with 65BC03JPP30A bearings and a 2.12 in shaft diameter. Business Impact: Extends service intervals and simplifies maintenance routines, lowering lifecycle costs. Application: OEM integrations and retrofit projects on existing Baldor-Reliance driven lines. Feature: Immediate availability across multiple warehouses (US, EU, Asia). Business Impact: Minimizes downtime and speeds project ramp-up with 0-day lead time. Application: Emergency maintenance, capital projects, and rapid prototyping in industrial plants. Insight: Real-world installations report easier sourcing and compatibility with standard Baldor-Reliance components, reducing vendor management burden.
Get a Quick Quote for a ABB 7BIDDRPM25606
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BIDDRPM25606?
Enquire Now
FAQs
The motor is foot-mounted with horizontal orientation (Mounting Position F1) and a frame RL2578. It operates as a 3-phase, 460 V motor with a 2.12 in shaft diameter and 73 A rated current. Compatible with DPFV enclosures and standard Baldor-Reliance assemblies, the unit supports straightforward alignment with existing conveyors, pumps, and fans while simplifying maintenance access.
Key specs include 60 HP output, 460 V line voltage, 73 A current, 3 phases, and a synchronous speed of 1200 r/min. Insulation class is H, indicating good thermal resilience. The laminated frame contributes to thermal efficiency, while the 3-phase design supports consistent torque delivery and improved efficiency in continuous duty services.
Yes. With a continuous-duty rating, 60 HP output, and a rugged DP-FV enclosure, it is well-suited for conveyors, pumps, and mixers in process and manufacturing environments. Its laminated frame and robust bearings provide longevity under steady-state operation, helping to minimize unplanned downtime and facilitate predictable production uptime.
The motor carries NEMA-standard alignment and is certified as CCSA US with UR recognition, ensuring UL-listed compatibility for diverse installations. This combination supports regulatory compliance across North American facilities and helps streamline integration with safety and performance requirements.
Warranty returns are handled with a policy that requires the product to be returned if under warranty. The motor is stocked at multiple warehouses (US, EU, Asia), offering 0-day lead times for many orders. This availability supports faster ROI through reduced downtime and easier serviceability in urgent maintenance scenarios.
