ABB IDM2276T Inverter - TEBC Enclosure IE3 Premium
Part Number: 7BIDM2276T
Quick Summary
ABB IDM2276T is an AC inverter used for vector-duty motor control in industrial drives. Engineers implement it to optimize speed, torque, and energy use on 3-phase motors across manufacturing lines. The challenge often lies in achieving precise ramping, reliable start-stop performance, and seamless integration with existing ABB or Baldor-Reliance components. This model delivers TEBC enclosure protection, 60 Hz compatibility, and dual voltage operation (230/460 V) with IE3 premium efficiency, helping plants meet regulatory targets. By aligning with North American stock, short lead times, and broad warehouse coverage, the IDM2276T supports lean maintenance and reduced downtime for automation projects.
Product Information
Extended Description
7BIDM2276T ABB: AC Inverter / Vector Duty 7.5 Hp 230 V (IDM2276T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
54M 6P TEBC HOR 254TC T'STATS INV
Altitude
1000 m
Ambient Temperature
40 °C
Base Speed
1200 r/min
Bearing
6309, Ball
Bearing NDE
6208
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDM2276T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
09LYT110: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
254
Frequency (f)
60 Hz
Global Commercial Alias
IDM2276T
Gross Volume
24317.313 in³
Gross Weight
332 lb
IC Class
TEBC
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
54M 6P TEBC HOR 254TC T'STATS INV DUTY
Lubrication
Regreasable
Made To Order
No
Maximum Speed
5000 r/min
Medium Description
AC Inverter / Vector Duty, 7.5 HP, 1200 RPM, Frame Size 254Tc, C-Face Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (IDM2276T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
254TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
7.5 Hp
Power Factor
71 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
43.25 in
Product Net Height
21.625 in
Product Net Weight
332 lb
Product Net Width
26 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
21.4 A | 10.7 A
Rated Efficiency
91 %
Rated Speed
1180 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.63 in
Short Description
7.5 HP, 1200 RPM, Frame Size 254Tc, C-Face, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101106
Voltage Code
J
Voltage Rating
230 V | 460 V
Vector-duty operation with a 7.5 HP output enables precise speed and torque control across varying loads. Business impact: reduced process variation and improved product consistency while lowering energy use. Application: conveyors, packaging lines, and machine-tool feeders that require reliable ramping and repeatable performance. TEBC enclosure with 254TC frame and C-face mounting enhances ruggedness. Business impact: easier installation in harsh factory environments and compatibility with standard mounting footprints. Application: retrofit into existing Baldor-Reliance motors and new builds in demanding spaces. 230/460 V, 60 Hz three-phase input expands plant-wide compatibility. Business impact: minimizes rewiring and downtime during upgrades. Application: legacy motors and VFDs across manufacturing and process lines. IE3 premium efficiency plus direct-on-line starting reduces energy bills and simplifies control schemes. Business impact: lower operating costs and simpler electrical architectures. Application: continuous-duty drives in automation loops. Ready-to-stock with 0-day lead times and multiple warehouses. Business impact: faster project kickoffs and reduced spare-part risk. Application: rapid deployment for urgent production lines. 3-phase, 6-pole design with Synchronous 1200 r/min and Rated Speed ≈1180 r/min. Business impact: predictable machine dynamics and improved process stability. Application: high-throughput conveyors and machine tools.
