ABB IDM4115T AC Inverter / Vector Duty - CSA UR
Part Number: 7BIDM4115T
Quick Summary
ABB IDM4115T AC Inverter / Vector Duty drives precise motor control for 50 HP systems in manufacturing and process environments. This drive helps optimize start-up sequences, protect mechanicals, and reduce energy use on demanding loads. The IDM4115T carries CSA | UR certification, a TEBC enclosure, and Premium Efficiency ratings, supporting regulatory compliance and lower operating costs. Designed for 3-phase 230/460 V at 60 Hz, it integrates smoothly with ABB automation stacks to simplify installation and maintenance while delivering reliable performance in harsh factory settings. With a 50 HP rating and a 326T frame, it fits conveyors, pumps, and processing lines, and its regreasable bearings support long service intervals.
Product Information
Extended Description
7BIDM4115T ABB: AC Inverter / Vector Duty 50 Hp 230 V (IDM4115T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
50HP,1775RPM,3PH,60HZ,326T,1272M,TE
Altitude
1000 m
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6312, Ball
Bearing NDE
6311
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDM4115T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
12LYT107: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
326
Frequency (f)
60 Hz
Global Commercial Alias
IDM4115T
Gross Volume
27401 in³
Gross Weight
645 lb
IC Class
TEBC
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
50HP,1775RPM,3PH,60HZ,326T,1272M,TEBC,F1
Lubrication
Regreasable
Made To Order
No
Maximum Speed
3900 r/min
Medium Description
AC Inverter / Vector Duty, 50 HP, 1800 RPM, Frame Size 326T, Standard Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (IDM4115T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
326T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
50 Hp
Power Factor
85 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
44 in
Product Net Height
23.5 in
Product Net Weight
645 lb
Product Net Width
26.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
116 A | 58 A
Rated Efficiency
94.50 %
Rated Speed
1775 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
2.13 in
Short Description
50 HP, 1800 RPM, Frame Size 326T, Standard, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101106
Voltage Code
H
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: High-power 50 HP, 3-phase, 60 Hz, 230/460 V capability enables direct drive of mid-weight loads with precise vector control, improving torque response and reducing motor stall conditions. This translates to smoother conveyors and pumps, lower maintenance costs, and improved line throughput. Application: Suitable for manufacturing lines, packaging systems, and processing equipment where reliable start/stop behavior is critical. Feature → Business Impact → Application: TEBC enclosure with insulation class H provides rugged protection against heat, dust, and moisture, extending motor life in harsh environments and reducing unscheduled downtime. Application: Food & beverage, chemical, and heavy industry plants with demanding ambient conditions. Feature → Business Impact → Application: Premium Efficiency (94.50%) delivers measurable energy savings across continuous operations, lowering operating costs and supporting sustainability initiatives. Application: Long-running process lines and OEM equipment aiming for energy performance credits. Feature → Business Impact → Application: Direct On Line starting simplifies control architecture, lowers upfront component counts, and reduces commissioning time, improving uptime during plant startups. Application: Fans, pumps, and conveyors requiring fast, reliable starts. Feature → Business Impact → Application: 326T frame, foot-mounted / horizontal mounting (F1), 2.13 in shaft, and robust bearings (6312 ball) promote easy retrofit, streamlined alignment, and reliable mechanical coupling. Application: Machine tools, packaging lines, and material handling where quick installation matters. Feature → Business Impact → Application: Stocked-at capabilities and 0-day lead time reduce project lead times and inventory risk, enabling rapid deployment on critical automation projects. Application: OEM retrofits and new line builds requiring fast delivery and predictable maintenance windows.
