ABB 7BIDNM2237T AC Inverter / Vector Duty - Premium Efficiency
Part Number: 7BIDNM2237T
Quick Summary
ABB 7BIDNM2237T AC Inverter / Vector Duty drives precise motor control for industrial automation and processing lines. This 7.5 HP, 3-phase drive operates at 230/460 V and 60 Hz to optimize speed, torque, and energy use across conveyors, pumps, and fans. The challenge in many facilities is achieving reliable performance without sacrificing efficiency or compatibility with legacy equipment. The 7BIDNM2237T helps reduce downtime through direct-on-line startup, robust protection, and a compact 254TC frame that fits common installations. It carries CSA and UR certifications and a NEMA Premium Efficiency designation, underscoring compliance and long-term savings. By aligning with standard mounting, domain knowledge in motor control, and turnkey installation support, you can accelerate projects and lower total cost of ownership.
Product Information
Extended Description
7BIDNM2237T ABB: AC Inverter / Vector Duty 7.5 Hp 230 V (IDNM2237T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
7.5HP,1765RPM,3PH,60HZ,254TC,0932M,
Altitude
1000 m
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6309, Ball
Bearing NDE
6208
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDNM2237T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
09LYF278: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Iron
Frame Size
254
Frequency (f)
60 Hz
Global Commercial Alias
IDNM2237T
Gross Volume
9651.933 inÂł
Gross Weight
117.027 kg
IC Class
TENV
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
7.5HP,1765RPM,3PH,60HZ,254TC,0932M,TENV
Lubrication
Regreasable
Made To Order
No
Maximum Speed
5000 r/min
Medium Description
AC Inverter / Vector Duty, 7.5 HP, 1800 RPM, Frame Size 254Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (IDNM2237T
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
254TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
7.5 Hp
Power Factor
81 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
27 in
Product Net Height
17.438 in
Product Net Weight
117.027 kg
Product Net Width
20.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
18.2 A | 9.1 A
Rated Efficiency
91.70 %
Rated Speed
1765 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.63 in
Short Description
7.5 HP, 1800 RPM, Frame Size 254Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101106
Voltage Code
H
Voltage Rating
230 V | 460 V
Feature → The inverter drive delivers vector-duty performance for precise speed control, improving torque response and process stability. Business Impact → Expect reduced energy consumption and tighter control of loads such as conveyors and pumps, translating into lower operating costs. Application → Ideal for manufacturing lines requiring smooth ramping and accurate motor performance in 3-phase systems. Feature → Compatibility with 230 V / 460 V, 60 Hz power and a 7.5 HP rating. Business Impact → Enables seamless integration with existing US electrical infrastructures and standard motor fleets, reducing wiring and configuration gaps. Application → Suitable for retrofit projects and new installations in food & beverage, packaging, and automation facilities. Feature → 254TC frame with C-Face mounting and foot-mounted configuration. Business Impact → Simplifies retrofits and field upgrades with common mounting footprints, minimizing downtime. Application → Conveyor drives, fans, and pump packages that need straightforward mechanical integration. Feature → TENV enclosure and H insulation class for robust operation in moderate environments. Business Impact → Enhances reliability in production floors with dust and temperature variation, lowering maintenance frequency. Application → Industrial environments where temperature and enclosure protection matter. Feature → Direct On Line starting and 3-phase operation with a 1.63 in shaft diameter. Business Impact → Fast, simple startup with minimal external components, reducing capital expenditure. Application → Quick deployment on new lines or upgrades to existing motor systems. Feature → Premium Efficiency (91.70%) and NEMA-compatible design. Business Impact → Improves energy cost of ownership and aligns with energy compliance programs. Application → Energy-conscious facilities aiming to lower utility bills and meet sustainability goals.
