ABB 7BIDNM3534 AC Inverter / Vector Duty - CSA/UR
Part Number: 7BIDNM3534
Quick Summary
ABB 7BIDNM3534 is an AC inverter / vector drive designed for precise motor control in conveyors, pumps, and processing lines. Engineers often wrestle with achieving smooth speed regulation and torque reliability in demanding 3-phase setups without overstressing bearings or compromising uptime. This model carries CSA and UR certifications, a NEMA-design B compliant enclosure (TENV), and a compact 56C frame, delivering dependable operation in space-constrained installations. With 0.33 HP output and 230/460 V capability, it fits standard industrial power rails while smoothing retrofit transitions and simplifying spare-parts management for maintenance teams and procurement alike.
Product Information
Extended Description
7BIDNM3534 ABB: AC Inverter / Vector Duty 0.33 Hp 230 V (IDNM3534)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.33HP,1780RPM,3PH,60HZ,56C,3512M,TE
Altitude
1000 m
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDNM3534
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
35LYT995: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
IDNM3534
Gross Volume
3496.049 inÂł
Gross Weight
33 lb
IC Class
TENV
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
.33HP,1780RPM,3PH,60HZ,56C,3512M,TENV,F1
Lubrication
Regreasable
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
AC Inverter / Vector Duty, 0.33 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (IDNM3534)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.33 Hp
Power Factor
49 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
33 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.7 A | 0.85 A
Rated Efficiency
75.50 %
Rated Speed
1780 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.63 in
Short Description
0.33 HP, 1800 RPM, Frame Size 56C, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101106
Voltage Code
M
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The 0.33 HP output at 1780–1800 r/min in a 56C frame with 3-phase, 60 Hz capability enables precise torque control while minimizing drive size and cabling complexity, reducing installation time. This translates to measurable efficiency gains in small conveyor or pump applications and lowers energy waste during variable-speed operation. Application: Ideal for compact line automation, packaging, and material handling where space is at a premium. Feature → Business Impact → Application: The C-Face mounting and foot-mounted configuration simplify retrofit into existing equipment, enabling quick integration with standard motor bases and minimizing downtime during upgrades. Application: Retrofits in legacy Baldor/ABB motor systems and new 56C frame installations in tight electrical rooms. Feature → Business Impact → Application: TENV enclosure with robust thermal management improves reliability in shop floors and outdoor-vascular environments, reducing maintenance cycles and prolonging motor life. Application: Continuous-duty drives in dusty or warm environments, such as conveyors and mixers. Feature → Business Impact → Application: CSA | UR certifications and NEMA-aligned design ensure regulatory compliance and easier qualification for automotive, food, and pharma facilities; lowers procurement and audit friction. Application: Industry-standard compliance across US and international sites. Feature → Business Impact → Application: Stocked at multiple warehouses with 0 day lead time supports rapid deployment, lowers downtime, and improves service-level performance. Application: Just-in-time projects and emergency replacements. Feature → Business Impact → Application: High-level specs (230/460 V, 60 Hz, 0.33 HP, 1.7 A | 0.85 A) enable precise speed modulation and predictable startup, reducing mechanical shocks and extending equipment life. Application: Fans, pumps, and small conveyors requiring reliable motor control with minimal footprint.
Get a Quick Quote for a ABB 7BIDNM3534
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BIDNM3534?
Enquire Now
FAQs
Yes. The drive supports 230 V and 460 V three-phase operation at 60 Hz, delivering 0.33 HP with a rated current of 1.7 A / 0.85 A for appropriate motor matches and reliable DOL to vector speed transitions.
It uses a 56C frame with C-Face drive end flange and foot-mounting capability, designed for horizontal orientation and straightforward bolting to standard motor bases.
The unit features CSA and UR certification, with a NEMA-design B (TENV) enclosure. These designations help ensure regulatory compliance in diverse markets and simplify equipment qualification during audits.
Lead time is listed as 0 day, and the product is stocked at multiple warehouses, including US and China locations, enabling rapid deployment and minimal project delays.
Variable-speed control reduces energy usage and mechanical stress, with an rated efficiency around 75.50% at 60 Hz. Direct On Line starting minimizes startup transients, potentially lowering maintenance costs and extending motor life in conveyors and pumps.
