ABB 7BIDVSWDM3558T Washdown Motor - IE3 Premium
Part Number: 7BIDVSWDM3558T
Quick Summary
Washdown motor performance for hygienic, 3-phase applications in food, beverage, and pharmaceutical lines. This ABB model delivers a rugged, corrosion-resistant solution designed to withstand washdown environments while maintaining reliable horsepower. Operators face downtime from enclosure leakage, corrosion, and inconsistent lubrication; this motor’s TEFC enclosure, stainless steel frame, and life-time lubrication address those challenges. With premium IE3 efficiency and CSA/UR recognition, it combines compliance with lower energy costs and extended motor life. The 2 HP rating at 230/460 V, 60 Hz, and 145TC frame aligns with standard industrial footprints, making installation straightforward and compatible with existing drives, starters, and motor bases. It’s a workhorse for continuous operation in clean-in-place and high-hygiene facilities.
Product Information
Extended Description
7BIDVSWDM3558T ABB: Washdown Motor 2 Hp 230 V (IDVSWDM3558T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1760RPM,3PH,60HZ,145TC,3528M,TE
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDVSWDM3558T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
35LYSS636: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Stainless Steel
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
IDVSWDM3558T
Gross Volume
3496.049 in³
Gross Weight
46 lb
Horsepower Rating UL/CSA
2.000 Hp
IC Class
TEFC
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
2HP,1760RPM,3PH,60HZ,145TC,3528M,TEFC,F1
Lubrication
For life
Made To Order
No
Maximum Speed
4500 r/min
Medium Description
Paint-Free Washdown, 2 HP, 1800 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (IDVSWDM3558T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
145TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
75 %
Product Name
Paint-Free Washdown
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
46 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.8 A | 2.9 A
Rated Efficiency
86.50 %
Rated Speed
1750 r/min
Replaced Product ID (OLD)
7B35SS636G073G1
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.88 in
Short Description
2 HP, 1800 RPM, Frame Size 145Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101112
Voltage Code
L
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: TEFC enclosure with a paint-free finish protects internal windings from washdown liquids and cleaning chemicals, reducing corrosion and maintenance cycles while extending service life in high-hygiene environments. This translates to fewer unscheduled outages on conveyor lines or CIP systems and lower total cost of ownership in food, beverage, and pharmaceutical processing. Feature → Business Impact → Application: 2 HP, 1800 rpm, 3-phase, 60 Hz operation with a 145TC frame provides consistent torque and predictable performance for pumps and mixers in standard plant footprints, enabling straightforward integration with existing drives and starters across manufacturing floors. Feature → Business Impact → Application: Stainless steel frame and 0.88 in shaft diameter improve mechanical robustness against washdown stresses, delivering reliable operation on bottling lines, packaging, and material handling. Feature → Business Impact → Application: Life-time lubrication and maintenance-free design reduce downtime and service costs, boosting uptime for continuous processes in dairy, snack, and cosmetic production. Feature → Business Impact → Application: IE3 premium efficiency and NEMA design B rating support energy compliance programs and reduced operating costs, with CSA/UR certifications simplifying supplier qualification for regulated industries. Feature → Business Impact → Application: Direct On Line starting and 230/460 V options simplify electrical installation and wiring, minimizing installation time and hardware changes for plant upgrades or line expansions.
Get a Quick Quote for a ABB 7BIDVSWDM3558T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BIDVSWDM3558T?
Enquire Now
FAQs
This motor uses a 145TC frame with C-Face mounting and horizontal orientation (F1). It supports standard 3‑phase, 60 Hz systems at 230/460 V and is compatible with commonly used footless motor bases and direct-on-line starters, simplifying integration with existing drives and equipment on food processing or packaging lines.
The ABB 7BIDVSWDM3558T is a 3‑phase, 60 Hz motor rated at 2 HP with IE3 Premium efficiency. It operates on 230/460 V and offers a rated speed of 1750 r/min (synchronous 1800 r/min). The enclosure is TEFC, and insulation class is H, supporting reliable operation in challenging environments.
Yes. It features a paint-free washdown finish, TEFC enclosure, and a stainless steel frame, making it well-suited for high-hygiene applications such as food processing, beverage handling, and pharmaceutical packaging where frequent cleaning is common.
The motor is associated with CSA and UR recognition and adheres to NEMA design standards (design code B). It also meets IE3 efficiency requirements, supporting regulatory and energy-compliance programs in regulated industries.
With life-time lubrication and no maintenance required for lubrication, the motor minimizes downtime and maintenance costs. Its robust TEFC design and stainless frame extend service intervals, while 0-day lead times and widespread stocking support rapid plant upgrades and return on investment for continuous-process facilities.
