ABB 7BIDWNM3609T Washdown Motor - IE3 Premium
Part Number: 7BIDWNM3609T
Quick Summary
ABB 7BIDWNM3609T washdown motor delivers reliable 2 HP performance for hygienic, continuous-operation applications such as food processing, packaging lines, and sanitary conveyors. This footprint-matched 3-phase motor is designed to withstand demanding washdown environments, reducing downtime and maintenance costs. With IE3 Premium Efficiency, NEMA design B alignment, and CSA/UR certification context, it helps you meet energy and safety requirements across regulated sectors. Built for 60 Hz operation on 230/460 V, it integrates smoothly with standard 182TC frames and C-face mounting, delivering strong business value through longer service life, predictable performance, and lower operating costs in high-cleaning environments.
Product Information
Extended Description
7BIDWNM3609T ABB: Washdown Motor 2 Hp 230 V (IDWNM3609T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1760RPM,3PH,60HZ,182TC,3628M,TE
Altitude
1000 m
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
IDWNM3609T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
36LYJ565: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
182
Frequency (f)
60 Hz
Global Commercial Alias
IDWNM3609T
Gross Volume
5274.135 inÂł
Gross Weight
77 lb
Horsepower Rating UL/CSA
2.000 Hp
IC Class
TENV
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
H
Invoice Description
2HP,1760RPM,3PH,60HZ,182TC,3628M,TENV,F1
Lubrication
For life
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
White Washdown, 2 HP, 1800 RPM, Frame Size 182Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (IDWNM3609T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
182TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
73 %
Product Name
White Washdown
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
77 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.8 A | 2.9 A
Rated Efficiency
88.50 %
Rated Speed
1760 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
1.13 in
Short Description
2 HP, 1800 RPM, Frame Size 182Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101112
Voltage Code
M
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: 2 HP, 60 Hz, 230/460 V three-phase operation provides robust torque for conveyors, pumps, and processing equipment, enabling reliable startup via Direct On Line starting and reducing cycle times in production. This translates to consistent throughput in packaging lines and hygienic environments where uptime directly affects output. Feature → Business Impact → Application: TENV enclosure and washdown-friendly construction protect internal components from moisture and cleaning chemicals, extending motor life in food and beverage facilities while maintaining compliant surface cleanliness between shifts. Feature → Business Impact → Application: 182TC frame with C-Face mounting and foot-mounted base enables quick installation on existing bases and workflows, minimizing integration time and reducing retrofit costs for retrofit projects in hygienic manufacturing. Feature → Business Impact → Application: IE3 Premium Efficiency and rated 2 HP power class deliver energy savings over long-running shifts, lowering total cost of ownership for continuous-duty equipment like mixers and agitators in process lines. Feature → Business Impact → Application: Shaft diameter of 1.13 in and standard 182TC dimensions ensure compatibility with common drive components and gearboxes, facilitating straightforward replacements and spare-parts planning in maintenance programs. Feature → Business Impact → Application: Stocked at multiple warehouses with zero-day lead time supports rapid procurement and lean stocking strategies, improving just-in-time manufacturing and minimizing production interruption in capital-intensive facilities.
