ABB 7BIM3540A-P Motors - 1HP, 460V/380V, IP54
Part Number: 7BIM3540A-P
Quick Summary
ABB 7BIM3540A-P motors deliver reliable three-phase power for farm-duty and industrial drive applications. Engineered for environments requiring solid enclosure protection and space-efficient installation, these motors balance performance with long-term reliability. The unit carries CSA and UR certification, RoHS compliance, and a NEMA design code B, ensuring regulatory alignment and broad compatibility. With a TE enclosure and IP54 protection, the 460V/380V, 50/60 Hz motor is ready for mixed US and global power systems. For procurement teams, this translates to simplified stocking, predictable maintenance, and fewer part substitutions across projects—helping reduce downtime and total cost of ownership.
Product Information
Extended Description
7BIM3540A-P ABB: 460 V (IM3540A-P)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Inactive
Quote Only
No
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Inactive
Quote Only
No
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Inactive
Quote Only
No
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Inactive
Quote Only
No
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1740//1430RPM,3PH,60//50HZ,56YZ
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
NONE
Bearing NDE
6203
Brand / Label
Baldor-Reliance
Catalog Number
IM3540A-P
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Direction of Rotation
Both sides
Efficiency Level
IE1 | Not Regulated / Exempt
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
56
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
IM3540A-P
Gross Volume
3298.281 in³
Gross Weight
43 lb
Horsepower Rating UL/CSA
1.000 Hp
IC Class
TENV
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
IP Class
IP54
Insulation Class
ICLF
Invoice Description
1HP,1740//1430RPM,3PH,60//50HZ,56YZ,3523
Lubrication
Regreasable
Made To Order
No
Medium Description
3 Phase, TENV Enclosure, (IM3540A-P)
Minimum Order Quantity
1 piece
Motor Base Type
No Mounting
Motor Frame Size
56YZ
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Speeds
Single Speed
Order Multiple
1 piece
Power Factor
68 %
Product Name
Farm Duty Motors
Product Net Depth / Length
19 in
Product Net Height
12.625 in
Product Net Weight
43 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.7 A | 1.8 A
Rated Efficiency
80.0 %
Rated Speed
1,740 r/min | 1,430 r/min
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Short Description
3 PH, TENV,
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
S1
UNSPSC
26101103
Voltage Code
N
Voltage Rating
460 V | 380 V
Feature → Business Impact → Application: The TE/NV enclosure with IP54 protection minimizes ingress from dust and water, reducing unintended downtime in harsh industrial environments and enabling reliable operation in conveyors, pumps, and fans. Application: farm-duty and general-purpose drive systems in manufacturing lines benefit from lower maintenance and extended service intervals. Feature → Business Impact → Application: Voltage compatibility of 460 V / 380 V and dual-frequency support (50 Hz / 60 Hz) offers installation flexibility across US and international facilities, cutting spare parts and enabling quick redeployment across sites. Application: global projects and multi-site deployments gain reduced lead times and simplified compliance. Feature → Business Impact → Application: NEMA Design Code B and RoHS compliance provide regulatory alignment and energy-conscious operation, simplifying supplier audits and decreasing risk in regulated industries. Application: regulated environments with RoHS expectations and standard-drive components. Feature → Business Impact → Application: Regreasable lubrication and Direct On Line starting, plus a 4-pole, single-speed design, lower maintenance costs, reduce downtime, and shorten time to ramp up production in packaging lines and process equipment. Application: high-availability systems and high-cycle operations. Feature → Business Impact → Application: 1HP rating with robust IP54 protection supports rugged farm-duty and light-industrial tasks, enabling compact footprint installations without compromising reliability. Application: space-constrained installations where performance must be predictable. Compatibility statements and installation advantages: Stocked at US-origin and China warehouses, Made To Order: No, with straightforward mounting options and standard frame 56YZ, this motor integrates with common drive trains and replacement parts, minimizing downtime during component swaps.
