ABB 7BL1304-50 General Purpose Motor - 1PH Open Enclosure
Part Number: 7BL1304-50
Quick Summary
The ABB 7BL1304-50 General Purpose Motor is a compact, single‑phase driver delivering 0.5 HP at 110 V (with 220 V option) for open enclosure installations in light industrial equipment. This design supports fast integration and minimal downtime, helping engineers meet tight project schedules. Key certifications such as CE, CSA, and UR, along with RoHS compliance, ensure regulatory alignment and safe operation in sensitive environments. The combination of frame size 56, horizontal mounting, and direct-on-line starting provides a reliable, cost-effective foundation for conveyors, pumps, fans, and other single‑phase applications. Stocked across multiple warehouses enables rapid fulfillment, improving project velocity and total cost of ownership.
Product Information
Extended Description
7BL1304-50 ABB: General Purpose Motor 0.5 Hp 110 V (L1304-50)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5/.37KW,1440RPM,1PH,50HZ,56,3424LC
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6203 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
L1304-50
Certification Agency
CE | CSA | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85013100
Design
N
Dimension Diagram
34LYF005
Direction of Rotation
Both sides
Drive End Flange Type
Standard
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
50 Hz
Global Commercial Alias
L1304-50
Gross Volume
1400.25 in³
Gross Weight
29 lb
Horsepower Rating UL/CSA
0.500 Hp
IC Class
OPEN
IDEA Granular Category Code (IGCC)
1329 >> Single phase motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
B
Invoice Description
.5/.37KW,1440RPM,1PH,50HZ,56,3424LC,ODP
Lubrication
Regreasable
Made To Order
No
Medium Description
General Purpose 1PH Open, .5/.37 HP, 1500 RPM, Frame Size 56, Standard Mounting, 1 Phase, OPEN Enclosure, 110/220 V, 50 Hz (L1304-50
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.5 Hp
Power Factor
73 %
Product Name
General Purpose 1PH Open
Product Net Depth / Length
13.813 in
Product Net Height
9.375 in
Product Net Weight
29 lb
Product Net Width
10.813 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
7.4 A | 3.7 A
Rated Efficiency
62 %
Rated Speed
1425 r/min
Replaced Product ID (OLD)
7B34F353X075
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.25
Service Factor Percentage
1.25 %
Shaft Diameter
0.63 in
Short Description
.5/.37 HP, 1500 RPM, Frame Size 56, Standard, 1 PH, OPEN, 110/220 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101116
Voltage Code
J
Voltage Rating
110 V | 220 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature → Business Impact → Application. The 7BL1304-50 is a 0.5 HP, single‑phase motor rated for 110 V / 220 V, enabling flexible site installations and lower wiring complexity. This configuration reduces initial wiring costs and simplifies panel design for light industrial equipment. In practice, it powers small conveyors, pumps, and fans with predictable performance, helping facilities meet throughput targets while keeping energy use in check and maintenance needs minimal. Its open enclosure and foot-mounted, horizontal F1 mounting simplify installation, cooling, and service access, reducing commissioning time and enabling straightforward retrofits in existing lines. With a 60‑minute duty and regreasable bearings, operators gain extended service intervals and lower lifecycle costs, especially in environments where uptime matters. The motor’s RoHS and NEMA-aligned design offers compatibility with standard parts, easing spares management and future upgrades. Industry-specific context shows that frame size 56 and 1425 r/min ratings align with common synchronous and load profiles in packaging, machine tooling, and material handling, delivering measurable efficiency (62%) and a favorable service factor (1.25) for continuous operation within duty cycles typical in light automation. Overall, this ABB motor supports faster installations, improved reliability, and lower total cost of ownership in industrial settings.
