ABB L1307-50 Motor - 110V, 1PH, 1500 RPM CE/CSA
Part Number: 7BL1307-50
Quick Summary
ABB L1307-50 motor is a general-purpose single-phase drive for open-frame manufacturing equipment. When downtime hits, a fast, compatible replacement minimizes production loss and simplifies procurement. This design carries CE, CSA, UR, and WEEE certifications, with NEMA frame compatibility and an open enclosure for effective cooling. Stocked across multiple warehouses in the US and China ensures quick fulfillment, while 110/220 V operation and 50 Hz compatibility support varied automation architectures.
Product Information
Extended Description
7BL1307-50 ABB: General Purpose Motor 0.75 Hp 110 V (L1307-50)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75/.56KW,1450RPM,1PH,50HZ,56,3524L
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
L1307-50
Certification Agency
CE | CSA | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85013100
Design
N
Dimension Diagram
35LYD011
Direction of Rotation
Both sides
Drive End Flange Type
Standard
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
50 Hz
Global Commercial Alias
L1307-50
Gross Volume
2110.969 in³
Gross Weight
38 lb
Horsepower Rating UL/CSA
0.750 Hp
IC Class
OPEN
IDEA Granular Category Code (IGCC)
1329 >> Single phase motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
.75/.56KW,1450RPM,1PH,50HZ,56,3524LC,OPE
Lubrication
Regreasable
Made To Order
No
Medium Description
General Purpose 1PH Open, 0.75 HP, 1500 RPM, Frame Size 56, Standard Mounting, 1 Phase, OPEN Enclosure, 110/220 V, 50 Hz (L1307-50)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.75 Hp
Power Factor
79 %
Product Name
General Purpose 1PH Open
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
38 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9.6 A | 4.8 A
Rated Efficiency
66 %
Rated Speed
1415 r/min
Replaced Product ID (OLD)
7B35M497G603G1
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.25
Service Factor Percentage
1.25 %
Shaft Diameter
0.63 in
Short Description
0.75 HP, 1500 RPM, Frame Size 56, Standard, 1 PH, OPEN, 110/220 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101116
Voltage Code
J
Voltage Rating
110 V | 220 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature: Open enclosure enables efficient cooling and simplified maintenance; Business Impact: Reduced thermal stress, easier access, and lower enclosure costs; Application: Open-frame conveyors and small pumps benefit from straightforward service. Feature: 0.75 HP, 110/220 V, 1PH, 50 Hz capability; Business Impact: Flexible power sourcing and reliable start-up for light machinery; Application: Fitment into compact automation lines with standard supply. Feature: Frame Size 56 and foot-mounted, horizontal orientation; Business Impact: Easy installation with familiar mounting patterns; Application: Replacement for legacy NEMA designs with minimal rework. Feature: Regreasable lubrication, service factor 1.25, insulation class F; Business Impact: Longer life, predictable performance, and better thermal protection; Application: Continuous-duty small drives in demanding environments. Feature: RoHS/CE/CSA/UR compliance and fast stock; Business Impact: Smooth procurement, legal compliance, and reduced downtime; Application: Global manufacturing environments with cross-border sourcing.
