ABB 7BPL1327M Pump Motor - CSA UR
Part Number: 7BPL1327M
Quick Summary
ABB 7BPL1327M Pump Motor is a 5 HP, 230 V single-phase drive designed for pressure washers and industrial cleaning equipment. This motor targets reliability and uptime in demanding environments, reducing unscheduled downtime and maintenance costs. It carries CSA and UR approvals with RoHS compliance, aligning with electrical safety and environmental requirements. Built for straightforward installation and long service life, it fits standard 56 frame mounts and offers direct-on-line starting for quick, predictable startups in field applications. For procurement teams, this translates to consistent performance, minimized spare-part diversity, and improved total cost of ownership.
Product Information
Extended Description
7BPL1327M ABB: Pump Motor 5 Hp 230 V (PL1327M)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,3450RPM,1PH,60HZ,56/56H,3535LC,
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
PL1327M
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYL203: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
ODTF
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
PL1327M
Gross Volume
3496.049 inÂł
Gross Weight
56 lb
Horsepower Rating UL/CSA
5.000 Hp
IC Class
ODTF
IDEA Granular Category Code (IGCC)
1324 >> Pressure washer motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
F
Invoice Description
5HP,3450RPM,1PH,60HZ,56/56H,3535LC,ODTF
Lubrication
Regreasable
Made To Order
No
Medium Description
Pressure Washer, 5 HP, 3600 RPM, Frame Size 5656H, Standard Mounting, 1 Phase, ODTF Enclosure, 230 V, 60 Hz (PL1327M)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56/56H
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
95 %
Product Name
Pressure Washer
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
56 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
23 A
Rated Efficiency
74.20 %
Rated Speed
3450 r/min
Replaced Product ID (OLD)
7B35L203S322
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.63 in
Short Description
5 HP, 3600 RPM, Frame Size 5656H, Standard, 1 PH, ODTF, 230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101111
Voltage Code
F
Voltage Rating
230 V
Feature: 5 HP output with 230 V single-phase operation at 60 Hz delivers the necessary torque for high-demand cleaning cycles. Business Impact: Enables rapid pressure-washer response with reliable startup behavior, reducing cycle times and workload on ancillary drive components. Application: Ideal for industrial cleaning equipment and shop floor washers that require dependable, single-phase power. Feature: 3450 r/min nominal speed with 2P design and frame 56/56H ensures compatibility with common mounting footprints. Business Impact: Streamlines retrofits and replacements, limiting customization and downtime during maintenance windows. Application: Fits standard 56-frame motors used in pressure washer assemblies and accessory drives. Feature: ODTF enclosure and direct-on-line starting provide rugged protection and immediate motor engagement. Business Impact: Enhances resistance to dust and splashes while eliminating soft-start delays, boosting productivity and protective capabilities in harsh environments. Application: Suitable for wash-down areas and outdoor use where simple, robust operation is required. Feature: Regreasable bearings (6205) with steel frame construction improves durability and service intervals. Business Impact: Lowers total maintenance cost through extended bearing life and predictable lubrication cycles. Application: Common in tough industrial settings where splash-heavy cleaning processes are routine. Feature: RoHS compliant, CSA | UR certified, and NEMA-aligned design deliver regulatory confidence and safe integration. Business Impact: Reduces compliance risk for audits and accelerates procurement approvals. Application: Essential for facilities that require certified motor solutions for clean environments and electrical safety standards. Feature: Foot-mounted, horizontal mounting with F1 configuration and 56 frame size supports straightforward installation and compatibility. Business Impact: Minimizes installation time, simplifies alignment, and improves vibration damping in compact machinery layouts. Application: Widely adopted in portable pressure-washer units and compact industrial cleaners.
Get a Quick Quote for a ABB 7BPL1327M
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BPL1327M?
Enquire Now
FAQs
Yes. The 7BPL1327M is a 230 V, 1-phase motor designed around a 56/56H frame. It supports foot-mounted, horizontal mounting in common pressure washer configurations and aligns with standard direct-on-line starting, making it a straightforward replacement in existing 56-frame installations.
Key specs include 5 HP output, 3450 r/min rated speed, 23 A rated current, 230 V, 60 Hz, 1 phase, and a 56/56H frame. The motor uses a Direct On Line starting method and features an ODTF enclosure with a steel frame and regreasable bearings for durability.
Yes. It is designed for continuous-duty operation in pressure washer applications. The ODTF enclosure and robust 56 frame support reliable performance in wash-down environments, while RoHS compliance and CSA | UR certifications help ensure continued reliability under demanding commercial use.
The motor carries CSA and UR certifications, confirming electrical safety compliance. It is RoHS compliant and built to meet standard industry expectations like NEMA-based design practices. These certifications reduce compliance risk and simplify integration into regulated facilities.
Install as a foot-mounted, horizontal F1 motor on a compatible 56-frame base to minimize vibration and alignment issues. Regreasable bearings support longer maintenance intervals, reducing downtime. Regular lubrication following the manufacturer’s intervals, and keeping spare 6205 bearings on hand, help optimize uptime and lifecycle costs.
