ABB RL1324A Fan and Blower - CSA UR Certified
Part Number: 7BRL1324A
Quick Summary
ABB RL1324A Fan and Blower is a compact single‑phase air handling solution designed for cooling and ventilation in compact industrial equipment. It delivers steady airflow with a small footprint, helping OEMs fit into crowded control panels and tight enclosures. Engineers often wrestle with inconsistent airflow, high startup currents, and mounting challenges that drive downtime. This model carries CSA and UR certifications and aligns with NEMA expectations, simplifying regulatory compliance across regulated environments. With a 0.75 HP rating and 1725 RPM, it provides reliable performance at 60 Hz and dual voltage (115/230 V) for retrofit and new builds, backed by resilient mounting and robust Baldor-Reliance engineering for long-term reliability.
Product Information
Extended Description
7BRL1324A ABB: Fan and Blower 0.75 Hp 115 V (RL1324A)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75HP,1725RPM,1PH,60HZ,56,3424L,OPE
Altitude
1000 m
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
RL1324A
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85013100
Design
N
Dimension Diagram
34LYK018: Dimension Sheet
Direction of Rotation
Both sides
Drive End Flange Type
Resilient Mount
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
RL1324A
Gross Volume
2110.969 inÂł
Gross Weight
31 lb
Horsepower Rating UL/CSA
0.750 Hp
IC Class
OPEN
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
IE Class Data (50 Hz)
IE Class NA
IE Class Data (60 Hz)
IE Class NA
IM Class
F1
Insulation Class
B
Invoice Description
.75HP,1725RPM,1PH,60HZ,56,3424L,OPEN,F1
Lubrication
Regreasable
Made To Order
No
Medium Description
Fan and Blower, 0.75 HP, 1800 RPM, Frame Size 56, ResilientMount Mounting, 1 Phase, OPEN Enclosure, 115/230 V, 60 Hz (RL1324A)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.75 Hp
Power Factor
71 %
Product Name
Fan and Blower
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
31 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
10.8 A | 5.4 A
Rated Efficiency
71 %
Rated Speed
1725 r/min
Replaced Product ID (OLD)
7B34K18W168
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.63 in
Short Description
0.75 HP, 1800 RPM, Frame Size 56, ResilientMount, 1 PH, OPEN, 115/230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Temperature Class Default
--
Two Speed Motor
No
Type of Duty
Continuous
UNSPSC
26101105
Voltage Code
G
Voltage Rating
115 V | 230 V
Feature: 0.75 HP at 1725 RPM in a 1‑phase, 60 Hz system. Business Impact: Delivers consistent airflow with efficient energy use, reducing cooling losses and operational heat. Application: Ideal for small to mid‑sized machinery cooling in control panels and compact process equipment. The result is measurable performance gains and lower total cost of ownership. Feature: Frame Size 56 with Open Enclosure and Resilient Mount. Business Impact: Facilitates easier installation, vibration control, and rapid service access, cutting downtime during maintenance. Application: Suitable for inline ducting and panel mounting in industrial automation setups. Feature: Dual Voltage 115/230 V. Business Impact: Simplifies procurement and installation while enabling stock optimization across global sites. Application: Retrofit projects and new builds where voltage flexibility minimizes wiring changes. Feature: Direct On Line Starting. Business Impact: Reduces component count and startup complexity, improving reliability in harsh environments. Application: Crane, conveyor, and HVAC control systems where immediate torque is beneficial. Feature: Bearing 6203 Ball and Regreasable Lubrication. Business Impact: Extends service life and reduces unplanned maintenance with predictable lubrication schedules. Application: Continuous operation in demanding environments, lowering maintenance costs. Feature: Certifications CSA | UR and NEMA Alignment. Business Impact: Enhances compliance and safety for regulated industries, easing supplier qualification. Application: Suitable for automotive, food processing, and general industrial automation contexts. Insight: This product’s design leverages Baldor-Reliance heritage to deliver consistent torque, thermal stability, and installation confidence across multiple applications.
