ABB 7BVEBM3615T-S Short Series Brake - CE CSA
Part Number: 7BVEBM3615T-S
Quick Summary
ABB 7BVEBM3615T-S Short Series Brake provides precise braking for 5 HP, 3‑phase motors in industrial drives. If retrofits or misfits slow projects, this unit offers straightforward installation and broad compatibility with 184TC, C-face mounting. Certified to CE, CSA, and WEEE standards, it also aligns with IE3 efficiency and UR recognition for regulated environments. This brake reduces downtime, improves reliability, and supports cost-effective motor control in conveyors, packaging lines, and machine tools. With 60 Hz operation and 230/460 V capability, it supports flexible integration across standard industrial drives. Built to withstand typical workshop temperatures up to 40 °C, it maintains performance in demanding environments.
Product Information
Extended Description
7BVEBM3615T-S ABB: Short Series Brake 5 Hp 230 V (VEBM3615T-S)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1750RPM,3PH,60HZ,184TC,3642M,TE
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6206
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
VEBM3615T-S
Certification Agency
CE | CSA | CSA EEV | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
36LYM815: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
184
Frequency (f)
60 Hz
Global Commercial Alias
VEBM3615T-S
Gross Volume
7192.91 in³
Gross Weight
106 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
5HP,1750RPM,3PH,60HZ,184TC,3642M,TEFC,F1
Made To Order
No
Medium Description
Short Series Brake, 5 HP, 1800 RPM, Frame Size 184Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VEBM3615T-S)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
184TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
78 %
Product Name
Short Series Brake
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Weight
106 lb
Product Net Width
16.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
13.4 A | 6.7 A
Rated Efficiency
89.50 %
Rated Speed
1750 r/min
Replaced Product ID (OLD)
7B36M815S268G1
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Short Description
5 HP, 1800 RPM, Frame Size 184Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
The 7BVEBM3615T-S delivers 5 HP braking at 230/460 V with a 60 Hz three-phase supply and 1750 rpm. This combination provides predictable stop performance, minimizes motor rebound, and reduces wear on drive trains, extending equipment life and lowering maintenance costs. It is ideal for conveyors, packaging lines, and machine tools where precise stop and hold are critical. TEFC enclosure paired with 184TC frame and C-face mounting simplifies installation, protects the brake from dust and debris, and enables clean alignment with existing motor housings. Direct On Line starting capability and rated currents of 13.4 A / 6.7 A reduce wiring complexity and simplify starter sizing, speeding commissioning and improving spare-part compatibility. With IE3 premium efficiency (78% PF) the brake contributes to lower energy costs in continuous operation and reduces heat load in electrical cabinets. Certifications including CE, CSA (and EEV), UR, and WEEE ensure regulatory compliance across North American and international facilities, supporting audits and vendor qualification. The unit’s weight (~106 lb) and compact footprint (26.625 in L × 16.625 in W × 16.25 in H) fit standard plant spaces, enabling straightforward retrofits and modular expansion. Installation and maintenance are further facilitated by stock availability across multiple warehouses and clear warranty terms, reducing downtime during line changes or capacity upgrades.
