ABB 7BVEFWDM3546T Motor - IE3 Premium Efficiency
Part Number: 7BVEFWDM3546T
Quick Summary
ABB 7BVEFWDM3546T Motor is a washdown-rated 1 HP, 230/460 V three-phase solution for sanitary production equipment. In facilities with frequent cleaning and hygiene demands, downtime and corrosion risk can erode productivity. This motor complies with NEMA standards and carries CSA, CSA EEV, and UR certifications, supporting safe, regulatory-compliant operation. For procurement teams, the 1 HP washdown motor combines TEFC protection, 143TC frame, and 60 Hz compatibility to streamline installation, maintenance, and total cost of ownership. Its White Washdown design helps resist cleaning agents and provide easy sanitation without compromising performance. With global availability and standardized lead times, it supports consistent motor performance in harsh washdown environments across projects.
Product Information
Extended Description
7BVEFWDM3546T ABB: Washdown Motor 1 Hp 230 V (VEFWDM3546T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1770RPM,3PH,60HZ,143TC,3520M,TE
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
VEFWDM3546T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Dimension Diagram
35LYSS605: Dimension Sheet
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
143
Frequency (f)
60 Hz
Global Commercial Alias
VEFWDM3546T
Gross Volume
2110.969 in³
Gross Weight
36 lb
Horsepower Rating UL/CSA
1.000 Hp
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
1HP,1770RPM,3PH,60HZ,143TC,3520M,TEFC,F1
Made To Order
No
Medium Description
White Washdown, 1 HP, 1800 RPM, Frame Size 143Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VEFWDM3546T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
143TC
Motor Frame Suffix
TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
69 %
Product Name
White Washdown
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
36 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.2 A | 1.6 A
Rated Efficiency
85.50 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
1 HP, 1800 RPM, Frame Size 143Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
TEFC washdown enclosure protects against moisture and cleaning chemicals, reducing corrosion risk and extending service life. This is ideal for sanitary environments such as food processing, beverage, and pharmaceutical lines where frequent washdowns are the norm. The 1 HP, 4-pole design delivers reliable torque and consistent speed, supporting conveyors and packaging lines while minimizing mechanical wear during continuous operation at 60 Hz. The 143TC frame with C-Face mounting and horizontal orientation offers flexible, quick installation and alignment, reducing downtime during upgrades. IE3 premium efficiency, insulation class F, and a NEMA B design improve energy performance and reliability, lowering cooling demands in hot environments and contributing to lower operating costs. Dual voltage availability (230/460 V) for 3-phase operation simplifies wiring, reduces stocking complexity, and enables multi-site deployment with fewer adapters. Certifications including NEMA, CSA, CSA EEV, and UR provide regulatory readiness, while stock availability and a 0 day lead time support aggressive project schedules.
