ABB 7BVEUHM3546-5 Unit Handling - IE3 Premium
Part Number: 7BVEUHM3546-5
Quick Summary
ABB 7BVEUHM3546-5 Unit Handling enables reliable 1 HP motor performance for 575 V systems in automated material handling and packaging lines. For engineers tasked with minimizing downtime, sourcing, and ensuring compliance, a turnkey solution that fits standard footprints is crucial. This unit ships from multiple warehouses and boasts immediate availability, helping reduce project lead times and inventory costs. It carries essential certifications for global deployment, including CE, CSA, and UR recognized safety marks, along with CSA EEV and WEEE considerations for end-of-life handling. By combining TEFC enclosure, 56C frame, and 3-phase operation, it offers predictable torque and efficiency. The design supports easy installation, serviceability, and scalable integration into existing ABB Baldor-Reliance motor ecosystems.
Product Information
Extended Description
7BVEUHM3546-5 ABB: Unit Handling 1 Hp 575 V (VEUHM3546-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1/.75KWHP,1774 1/MINRPM,3PH,60HZ,56
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
VEUHM3546-5
Certification Agency
CE | CSA | CSA EEV | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Dimension Diagram
35LYX042
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
VEUHM3546-5
Gross Volume
3496.049 inÂł
Gross Weight
38 lb
Horsepower Rating UL/CSA
1.000 Hp
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
1/.75KWHP,1774 1/MINRPM,3PH,60HZ,56C,352
Made To Order
No
Medium Description
Unit Handling, 1 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TEFC Enclosure, 575 V, 60 Hz (VEUHM3546-5)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F3
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
67 %
Product Name
Unit Handling
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
38 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.3 A
Rated Efficiency
85.50 %
Rated Speed
1774 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.63 in
Short Description
1 HP, 1800 RPM, Frame Size 56C, C-Face, 3 PH, TEFC, 575 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
575 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature → Business Impact → Application: The 56C frame with TEFC enclosure provides a compact, rugged footprint that fits tight spaces while protecting windings from dust and moisture; this translates to higher machine availability and lower maintenance costs in conveyor and packaging lines. Feature → Business Impact → Application: 1 HP at 575 V, 3-phase with Direct On Line starting simplifies startup sequences, reducing commissioning time and unplanned downtime on automated material handling systems. Feature → Business Impact → Application: IE3 premium efficiency and insulation class F deliver measurable energy savings during continuous operation, lowering operating costs for high-demand processes like sortation and palletizing. Feature → Business Impact → Application: Stocked at multiple warehouses with 0-day lead times improves project scheduling, enables rapid replacements, and minimizes spare-part inventory for Baldor-Reliance driven fleets. Feature → Business Impact → Application: NEMA Design Code B and 56C, C-Face mounting ensure predictable torque and easy cross-compatibility with existing drive trains, supporting straightforward installation in general-purpose, continuous-duty applications. The combination of these characteristics supports seamless integration with the Baldor-Reliance motor ecosystem, enhancing overall line reliability and reducing total cost of ownership.
