ABB 7BVEUHM3611T Motor - 3HP 230V TEFC 182TC CE/CSA
Part Number: 7BVEUHM3611T
Quick Summary
ABB 7BVEUHM3611T motor provides reliable 3 HP power for unit handling in material handling and packaging lines. This rugged design addresses downtime, energy waste, and maintenance overhead that challenge automated systems. Certified for CE, CSA, and UR listings, the drive is built for safe, compliant operation in industrial environments. With a TEFC enclosure, 182TC frame, and 230/460 V three-phase supply, it delivers consistent torque and quick integration with existing controls. The result is improved line uptime, lower total cost of ownership, and scalable performance across multiple line configurations. Designed for continuous operation, it supports straightforward retrofits and minimal integration risk.
Product Information
Extended Description
7BVEUHM3611T ABB: Unit Handling 3 Hp 230 V (VEUHM3611T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,1760RPM,3PH,60HZ,182TC,3632M,TE
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
VEUHM3611T
Certification Agency
CE | CSA | CSA EEV | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
36LYA003
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
182
Frequency (f)
60 Hz
Global Commercial Alias
VEUHM3611T
Gross Volume
5274.135 in³
Gross Weight
73 lb
Horsepower Rating UL/CSA
3.000 Hp
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
3HP,1760RPM,3PH,60HZ,182TC,3632M,TEFC,F1
Made To Order
No
Medium Description
Unit Handling, 3 HP, 1800 RPM, Frame Size 182Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VEUHM3611T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
182TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
75 %
Product Name
Unit Handling
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
73 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
8.4 A | 4.2 A
Rated Efficiency
89.50 %
Rated Speed
1760 r/min
Replaced Product ID (OLD)
7B36A003S266G1
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
1.13 in
Short Description
3 HP, 1800 RPM, Frame Size 182Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature: 3 HP, 1760 r/min three-phase operation at 60 Hz with dual voltage (230/460 V). Business Impact: Delivers reliable torque for unit-handling tasks, reduces drive sizing and wiring complexity, and minimizes voltage-specific stocking. Application: Suitable for conveyors, sorters, and transfer drives in packaging and assembly lines. Feature: TEFC enclosure. Business Impact: Provides protection against dust, moisture, and contaminants on busy shop floors, increasing uptime and reducing maintenance. Application: Ideal for manufacturing floors and assembly lines where cleanliness and enclosure integrity matter. Feature: 182TC frame with C-Face mounting and horizontal orientation. Business Impact: Enables fast, drop-in installation and straightforward alignment with existing conveyors, gearboxes, or pulleys. Application: Retrofit projects and new line builds where space and alignment are critical. Feature: High efficiency (≈89.5%) and insulation class F. Business Impact: Lower energy costs in continuous-duty operation and better thermal management, extending motor life. Application: Continuous-process conveyors and material-handling systems in demanding environments. Feature: Direct On Line starting, 3-phase, 4-pole, NEMA B design. Business Impact: Simplifies start-up sequencing, reduces control hardware, and improves immediate torque for load-inertia. Application: Packaging lines and robotic-assisted units that require reliable, simple startup. Feature: Balanced mechanical design with 6206 ball bearings and a 40 °C ambient rating. Business Impact: Improves reliability, reduces lubrication needs, and supports long service intervals. Application: Industrial-duty conveyors and packaging equipment operating in moderate ambient temperatures. Overall, the motor’s compatibility with 230 V or 460 V supply, rugged TEFC enclosure, and standard mounting options enable smoother installation, faster ROI, and scalable performance across multiple line configurations in manufacturing and logistics environments.
