ABB 7BVEWDM3559T Washdown Motor - CSA EEV UR
Part Number: 7BVEWDM3559T
Quick Summary
ABB 7BVEWDM3559T Washdown Motor delivers reliable 3 HP power for sanitary processing lines. In demanding washdown environments, moisture and aggressive cleaners can shorten motor life and increase maintenance. This model features a TEFC enclosure, a durable 145TC frame, and a C-face mounting design to withstand frequent washdowns and harsh cleaning cycles. With certifications including CSA, CSA EEV, and UR, it meets regulatory safety requirements while delivering energy-efficient operation. Stocked across multiple warehouses for fast procurement, it supports 230/460 V 3-phase systems and helps reduce downtime and total cost of ownership for food & beverage, pharmaceutical, and packaging applications.
Product Information
Extended Description
7BVEWDM3559T ABB: Washdown Motor 3 Hp 230 V (VEWDM3559T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,3450RPM,3PH,60HZ,145TC,TEFC,F1
Ambient Temperature
40 °C
Bearing
6205 | Ball
Bearing NDE
6203 | Ball
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
VEWDM3559T
Certification Agency
CSA | CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYZ299
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
VEWDM3559T
Gross Volume
3496.049 in³
Gross Weight
50 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
3HP,3450RPM,3PH,60HZ,145TC,TEFC,F1
Made To Order
No
Medium Description
White Washdown, 3 HP, 3600 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VEWDM3559T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
145TC
Motor Frame Suffix
TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
92 %
Product Name
White Washdown
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
50 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
7.2 A | 3.6 A
Rated Efficiency
86.50 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
3 HP, 3600 RPM, Frame Size 145Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: TEFC washdown enclosure and 40 °C ambient rating protect windings from moisture and chemical exposure, extending motor life and reducing maintenance cycles; ideal for sanitary lines in food and beverage or pharma equipment. Feature → 3 HP, 60 Hz, 230/460 V, 3-phase with 145TC frame → ensures compatibility with common plant voltages and standard mounting footprints, enabling straightforward retrofit or new builds in manufacturing facilities. Feature → C-face mounting, horizontal orientation, and footless base → simplifies alignment, reduces installation time, and supports compact footprints in conveyor and packaging lines. Feature → Efficiency 86.50% and service factor 1.15 → delivers reliable performance with energy savings and improved productivity; suitable for continuous duty and variable loads. Feature → Stocked at multiple warehouses (EGAUT001, GBINS001, SGIND004, USABB014) with 0-day lead time → minimizes project delays and procurement risk, improving total cost of ownership. Feature → Certifications (CSA, CSA EEV, UR) and NEMA design B with insulation class F → ensures regulatory compliance and robust performance in demanding environments.
