ABB VFSWDNM3555-E Washdown Motor - NEMA Premium
Part Number: 7BVFSWDNM3555-E
Quick Summary
Washdown motor VFSWDNM3555-E delivers reliable torque for hygienic food processing applications. When uptime matters, frequent washdowns and moisture exposure threaten equipment life and productivity, but this ABB design resists corrosion with a stainless steel frame and sealed bearings. The unit carries CSA EEV, UR, and NEMA Premium efficiency certifications, underscoring regulatory compliance and energy savings. With 3-phase, 60 Hz operation and a 56C frame, it's compatible with common industrial drives and VFDs. The motor's rugged construction supports long service intervals and predictable maintenance, translating to lower total cost of ownership. In short, it combines food-safety performance with installation versatility for automated lines in beverage, meat, or dairy processing.
Product Information
Extended Description
7BVFSWDNM3555-E ABB: Washdown Motor 2 Hp 230 V (VFSWDNM3555-E)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,3480RPM,3PH,60HZ,56C,3546M,TENV
Ambient Temperature
40 °C
Bearing
6205, Sealed Bearing
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
VFSWDNM3555-E
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
35LYE4656
Drive End Flange Type
C-Face
Duty Time
60 Min
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Stainless_Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
VFSWDNM3555-E
Gross Volume
3496.049 in³
Gross Weight
63 lb
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
H
Invoice Description
2HP,3480RPM,3PH,60HZ,56C,3546M,TENV,F1,N
Made To Order
No
Medium Description
Food Safe Washdown, 2 HP, 3600 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (VFSWDNM3555-E)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56C
Motor Frame Suffix
C
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
89 %
Product Name
Food Safe Washdown
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
63 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.8 A | 2.4 A
Rated Efficiency
88.50 %
Rated Speed
3480 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
2 HP, 3600 RPM, Frame Size 56C, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
230 V | 460 V
The washdown-ready stainless steel frame and TENV enclosure reduce corrosion risk in washdown environments, delivering longer service life and lower maintenance costs in food processing lines. Feature → Business Impact → Application: Stainless steel frame and sealed bearings improve reliability under frequent cleaning, reducing downtime on packaging conveyors and meat, dairy, or beverage lines. The motor's 2 HP rating, 3480 rpm, 60 Hz, 230/460 V, and 3-phase design enable immediate integration with standard drives and VFDs, delivering predictable speed and energy savings (88.5% efficiency), which translates to lower operating costs on continuous-duty lines. Frame size 56C with C-face mounting and footless base supports easy installation and space optimization in retrofits and new builds. With CSA EEV, UR, and NEMA Premium certifications, compliance and performance are assured, addressing procurement objections and supplier audits. Stock availability and 0-day lead time further reduce downtime in critical manufacturing cells.
Get a Quick Quote for a ABB 7BVFSWDNM3555-E
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BVFSWDNM3555-E?
Enquire Now
FAQs
Yes. The VFSWDNM3555-E uses a 56C frame and C-face flange, with a horizontal mounting option and a footless base. It supports 3-phase, 60 Hz operation and direct-on-line starting for quick, straightforward installation in conveyor and processing lines.
The motor is 2 HP, 3480 rpm, 3-phase, 60 Hz, with dual voltage of 230/460 V. Rated current is 4.8 A / 2.4 A, service factor 1.15, and rated efficiency of 88.50%. It uses a TENV enclosure and insulation class H for demanding environments.
Yes. It features a stainless steel frame, sealed bearings, and a TENV enclosure designed for frequent washdowns. Ambient rating is 40 °C, making it well-suited for hygienic applications like dairy, meat, and beverage processing.
The motor carries CSA EEV, UR, and NEMA Premium efficiency certifications, ensuring regulatory compliance and energy performance suitable for strict industrial audits and performance standards.
With stock available across multiple warehouses and 0-day lead times, procurement minimizes downtime. The combination of energy efficiency (NEMA Premium), durable sealed bearings, and a long service life lowers maintenance costs, while easy installation reduces commissioning time.
