ABB VRBM3554T High Cycle Brake - 1.5HP, 230/460V, CSA/UR
Part Number: 7BVRBM3554T
Quick Summary
ABB VRBM3554T High Cycle Brake is a reliable braking solution for 1.5 HP, three‑phase motors used in demanding applications such as conveyors and automated material handling. This brake addresses common pain points like premature wear, unpredictable stopping, and excessive downtime by delivering consistent torque and stopping reliability. With certifications including CSA and UR, plus a NEMA design code D and a TEFC enclosure, the unit is built for rugged industrial environments. The design also supports a broad voltage range (230/460 V) and 60 Hz operation, aligning with standard plant electricals. For buyers evaluating downtime reduction and total cost of ownership, the VRBM3554T offers a proven balance of performance, safety, and value.
Product Information
Extended Description
7BVRBM3554T ABB: High Cycle Brake 1.5 Hp 230 V (VRBM3554T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1.5HP,1710RPM,3PH,60HZ,145TC,7524M,
Ambient Temperature
40 °C
Bearing
6205
Bearing NDE
6205
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
VRBM3554T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
75LYJ035
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE1 | Not Regulated / Exempt
Electrical Data
Enclosure Type
TEFC
Frame Material
Aluminum
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
VRBM3554T
Gross Volume
3590.443 in³
Gross Weight
63 lb
Horsepower Rating UL/CSA
1.500 Hp
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
Insulation Class
F
Invoice Description
1.5HP,1710RPM,3PH,60HZ,145TC,7524M,TEFC
Made To Order
No
Medium Description
High Cycle Brake, 1.5 HP, 1800 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VRBM3554T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
145TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
D
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1.5 Hp
Power Factor
80 %
Product Name
High Cycle Brake
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
63 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.3 A | 2.15 A
Rated Efficiency
81.50 %
Rated Speed
1710 r/min
Replaced Product ID (OLD)
7B75J035W130G1
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
1.5 HP, 1800 RPM, Frame Size 145Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: High-cycle capability and precise stopping torque reduce wear on driven equipment and extend motor life, improving uptime and reducing maintenance costs for high‑duty lines. Application: Conveyor belts and hoists in continuous operation, where consistent brake engagement minimizes surge loads and gearbox wear. Feature → Business Impact → Application: TEFC enclosure and aluminum frame provide robust protection in dusty, damp, and harsh environments, lowering risk of thermal or moisture-related failures. Application: Material handling and packaging lines in manufacturing plants requiring reliable protection against environmental factors. Feature → Business Impact → Application: C‑Face mounting and horizontal orientation simplify retrofits and new installations, decreasing installation time and enabling flexible placement in crowded control rooms. Application: OEM conveyor drives and shop floor automation where space is at a premium. Feature → Business Impact → Application: 230/460 V dual voltage and 60 Hz compatibility support standard industrial power distribution, reducing the need for voltage conversion and enabling fast commissioning. Application: New equipment builds and modernization projects with mixed electrical infrastructure. Feature → Business Impact → Application: 1.5 HP rating with 1710 rpm and a 145TC frame optimizes motor matching and drive performance, delivering predictable braking force at the exact operating speed. Application: High‑speed packaging, weighing systems, and automated sorting lines that require precise brake response. Feature → Business Impact → Application: Stocked at multiple warehouses with zero lead time, improving procurement agility and minimizing procurement risk. Application: Global operations needing rapid replacement parts and local support.
Get a Quick Quote for a ABB 7BVRBM3554T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BVRBM3554T?
Enquire Now
FAQs
The VRBM3554T is designed for 3-phase motors around 1.5 HP and uses C-face mounting with a horizontal mounting orientation. It fits a 145TC frame and a 0.88 in shaft diameter, and supports 230 V or 460 V operation at 60 Hz. It is TEFC enclosed for harsh environments. Ensure your motor base is footless and that your drive aligns with a Direct On Line starting method.
Key specs include 1.5 HP output, 1710 rpm rated speed, 60 Hz, and voltage ratings of 230 V / 460 V. Rated current is 4.3 A (primary) and 2.15 A (secondary in relevant configurations). The brake is designed for high-cycle duty with a service factor of 1.15 and a TEFC enclosure, suitable for continuous operation in demanding tasks.
Yes. The VRBM3554T is tailored for high-cycle braking in conveyors, hoists, and automated material handling. With a 1.5 HP rating, 1710 r/min speed, and a robust 145TC frame, it delivers consistent stopping torque, aiding alignment, safety, and productivity in these applications.
This brake carries CSA and UR safety certifications and aligns with NEMA design code D. It also features a TEFC enclosure, supporting protection against dust and moisture in typical industrial environments. These certifications help satisfy plant safety and equipment commissioning requirements.
The VRBM3554T’s high-cycle design and robust enclosure reduce unplanned downtime and wear-related maintenance. With stock availability across multiple warehouses and minimal lead times, procurement is streamlined, improving asset uptime and lowering operating costs over the equipment life cycle.
