ABB VRBM3558T High Cycle Brake - 2HP 230V (CSA/UR)
Part Number: 7BVRBM3558T
Quick Summary
ABB VRBM3558T High Cycle Brake is a compact, reliable braking solution for demanding conveyors and motor-driven equipment. In high-cycle environments, stopping reliability and downtime cost can escalate quickly; this brake delivers consistent engagement and long service life with minimal maintenance. It carries CSA and UR safety certifications and adheres to NEMA-compliant TEFC enclosures, providing safe operation in rugged industrial settings. For design engineers and maintenance teams, the solution integrates smoothly with 145TC-frame motors and C-Face mounting, delivering predictable control, reduced retrofit risk, and a lower total cost of ownership over the equipment lifecycle.
Product Information
Extended Description
7BVRBM3558T ABB: High Cycle Brake 2 Hp 230 V (VRBM3558T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1700RPM,3PH,60HZ,145TC,3528M,TE
Ambient Temperature
40 °C
Bearing
6205
Bearing NDE
6205
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
VRBM3558T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
75LYJ035
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Energy Efficiency (NEMA 12-11) | IE2 | Not Regulated / Exempt
Electrical Data
Enclosure Type
TEFC
Frame Material
Aluminum
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
VRBM3558T
Gross Volume
3590.443 inÂł
Gross Weight
69 lb
Horsepower Rating UL/CSA
2.000 Hp
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
Insulation Class
F
Invoice Description
2HP,1700RPM,3PH,60HZ,145TC,3528M,TEFC,F1
Made To Order
No
Medium Description
High Cycle Brake, 2 HP, 1800 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VRBM3558T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
145TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
D
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
77 %
Product Name
High Cycle Brake
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
69 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.8 A | 2.9 A
Rated Efficiency
84 %
Rated Speed
1700 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
2 HP, 1800 RPM, Frame Size 145Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
230 V | 460 V
2 HP, 1700 RPM, 60 Hz, 230/460 V TEFC brake with C-Face drive end flange and 145TC aluminum frame reduces integration time and supports standard 3-phase motor systems, enabling reliable stopping in conveyors and packaging lines. This feature set translates to lower downtime and improved production throughput, especially when retrofitting existing lines or engineering new systems with horizontal mounting and F1 position. The High Cycle design delivers repeatable engagement and durable operation, helping maintenance teams reduce wear on drive components and extend motor life in continuous-duty applications. Certifications and compliance (CSA, UR, NEMA) lower procurement risk and simplify regulatory approvals for regulated facilities, while a robust TEFC enclosure protects the brake in harsh environments. Stock availability and zero-day lead times enable rapid deployment for critical lines and just-in-time manufacturing needs. This combination supports long-term cost savings and predictable maintenance planning for industrial operations.
Get a Quick Quote for a ABB 7BVRBM3558T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BVRBM3558T?
Enquire Now
FAQs
The VRBM3558T uses a C-Face drive-end flange with a 0.88 inch shaft diameter, compatible with 145TC frame motors and horizontal mounting in the F1 position. This simplifies retrofits and new installations, reducing alignment time and ensuring a secure fit with standard motor appendages.
Yes. The brake is designed for 3-phase, 60 Hz systems and supports 230 V or 460 V operation. It delivers 2 HP at 1700 rpm, making it a practical brake solution for common industrial conveyors and processing lines.
The VRBM3558T carries CSA and UR safety certifications and aligns with NEMA standards for TEFC enclosures, which supports safe operation and regulatory compliance in many industrial facilities.
Lead time is listed as 0 day, and the product is stocked at multiple warehouses (e.g., US and other locations). This enables fast fulfillment and reduces downtime for urgent production needs.
Warranty returns are handled with the policy that products under warranty must be returned. For service, replacements, or returns, contact your supplier to coordinate inspection and RMA procedures.
