ABB VRBM3561T High Cycle Brake - CSA UR Certified
Part Number: 7BVRBM3561T
Quick Summary
ABB VRBM3561T High Cycle Brake is a robust braking solution for continuous-duty motor systems in industrial automation and machinery. Engineers confront wear and downtime from frequent braking; this brake is designed to withstand high-cycle duty with consistent performance. With CSA and UR certification, along with NEMA standards, the product is prepared for safe integration into regulated environments. The 3 HP rating at 230/460 V and 60 Hz covers a broad range of conveyors, presses, and packaging lines, while TEFC enclosure and aluminum frame support durable operation. This combination translates into reliable uptime and predictable maintenance costs for your facility.
Product Information
Extended Description
7BVRBM3561T ABB: High Cycle Brake 3 Hp 230 V (VRBM3561T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,1710RPM,3PH,60HZ,145TC,3540M,TE
Ambient Temperature
40 °C
Bearing
6205
Bearing NDE
6205
Brake Present
Yes
Brand / Label
Baldor-Reliance
Catalog Number
VRBM3561T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Design
B
Dimension Diagram
75LYJ035
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEFC
Frame Material
Aluminum
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
VRBM3561T
Gross Volume
3590.443 in³
Gross Weight
76 lb
Horsepower Rating UL/CSA
3.000 Hp
IDEA Granular Category Code (IGCC)
1328 >> Multi phase motor AC
Insulation Class
F
Invoice Description
3HP,1710RPM,3PH,60HZ,145TC,3540M,TEFC,F1
Made To Order
No
Medium Description
High Cycle Brake, 3 HP, 1800 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (VRBM3561T)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
145TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
D
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
80 %
Product Name
High Cycle Brake
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
76 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
8.2 A | 4.1 A
Rated Efficiency
84 %
Rated Speed
1710 r/min
Replaced Product ID (OLD)
7B75J035G299G1
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.88 in
Short Description
3 HP, 1800 RPM, Frame Size 145Tc, C-Face, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101115
Voltage Rating
230 V | 460 V
Feature: High-cycle braking capability. Benefit: Reduces wear on motors and drive systems, lowering maintenance costs in continuous operation. Application: conveyors and packaging lines. Feature: 145TC frame with C-Face mounting and horizontal F1 orientation. Benefit: Simplifies retrofits and minimizes installation time. Application: retrofit projects across existing lines. Feature: TEFC enclosure and aluminum frame. Benefit: Enhanced dust/moisture protection and lightweight handling, extending service life. Application: factory floors with typical ambient conditions. Feature: 60 Hz operation with 230/460 V three-phase supply. Benefit: Flexible power supply compatibility and improved control. Application: industrial automation systems and tool machines. Feature: Insulation class F and 6205 bearing. Benefit: Reliable performance under elevated temps and long bearing life. Application: demanding applications in manufacturing.
