ABB 7BVUHM3538-5 Unit Handling - CE/CSA/UR/WEEE
Part Number: 7BVUHM3538-5
Quick Summary
Unit Handling 7BVUHM3538-5 is a compact 0.5 HP, 575 V motor designed for dependable unit handling in material handling systems. Engineers often struggle with mounting compatibility, footprint constraints, and reliable startup in tight, TEFC enclosures. Built to CE, CSA, UR certifications with WEEE compliance, it ensures regulatory alignment for global installations. This ABB unit ships from multiple stocked warehouses for fast deployment, and its 56C frame, horizontal mounting, and C-face interface simplify installation. The combination of direct-on-line starting, a 0.6 A nominal current, and an 82.5% efficiency profile translates to lower energy costs and reduced downtime. In practice, it supports conveyors, packaging lines, and automated feeders with predictable performance and quick procurement.
Product Information
Extended Description
7BVUHM3538-5 ABB: Unit Handling 0.5 Hp 575 V (VUHM3538-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5/37KWHP,1770RPM,3PH,60HZ,56C,3512
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
VUHM3538-5
Certification Agency
CE | CSA | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85015100
Design
B
Dimension Diagram
35LYX042
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
56
Frequency (f)
60 Hz
Global Commercial Alias
VUHM3538-5
Gross Volume
3496.049 in³
Gross Weight
33 lb
Horsepower Rating UL/CSA
0.500 Hp
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
F
Invoice Description
.5/37KWHP,1770RPM,3PH,60HZ,56C,3512M,TEF
Made To Order
No
Medium Description
Unit Handling, 0.5 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, TEFC Enclosure, 575 V, 60 Hz (VUHM3538-5)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F3
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.5 Hp
Power Factor
74 %
Product Name
Unit Handling
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
33 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
0.6 A
Rated Efficiency
82.50 %
Rated Speed
1735 r/min
Replaced Product ID (OLD)
7B35X042G200G1
Selling Unit of Measure
piece
Service Factor
1.15
Service Factor Percentage
1.15 %
Shaft Diameter
0.63 in
Short Description
0.5 HP, 1800 RPM, Frame Size 56C, C-Face, 3 PH, TEFC, 575 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
575 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature → The ABB 7BVUHM3538-5 integrates 0.5 HP, 575 V three-phase operation in a 56C frame with TEFC enclosure, designed for compact installation and reliable performance. Business Impact → This combination reduces footprint, simplifies wiring, and improves ruggedness in demanding environments, delivering consistent torque and smoother operation on conveyors and hoists. Application → Ideal for automated material handling and packaging lines where space is limited and uptime is critical, enabling faster project completion and fewer field modifications. Long-tail keywords integrated → 575 V three-phase motor, 56C frame TEFC, direct-on-line starting, C-face mounting, 3-phase 60 Hz motor.
