ABB 7BYPC364A Direct Drive Fan Motor - CSA UR
Part Number: 7BYPC364A
Quick Summary
ABB 7BYPC364A Direct Drive Fan Motor delivers compact, reliable cooling for small industrial equipment such as fans, blowers, and process cooling lines. In many facilities, space constraints and wiring complexity make traditional belt-driven solutions laborious and costly; this motor's direct-drive design minimizes maintenance and footprint while improving efficiency. The unit is CSA and UR certified, RoHS compliant, and built to NEMA standards, ensuring safe, compliant operation in diverse environments. With TEAO enclosure, 1-phase 115 V operation, and a 48YZ frame, it plugs into standard plant power and simplifies installation. For manufacturers seeking predictable performance with easy service, this motor offers compelling total cost of ownership and quick ROI.
Product Information
Extended Description
7BYPC364A ABB: Farm Duty Motor 0.5 Hp 115 V (YPC364A)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5HP,1075RPM,1PH,60HZ,48YZ,3420C,TE
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
YPC364A
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85013100
Dimension Diagram
34LYM195
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
48
Frequency (f)
60 Hz
Global Commercial Alias
YPC364A
Gross Volume
3496.049 in³
Gross Weight
27 lb
Horsepower Rating UL/CSA
0.500 Hp
IDEA Granular Category Code (IGCC)
1318 >> Heating and cooling system motor AC
Insulation Class
B
Invoice Description
.5HP,1075RPM,1PH,60HZ,48YZ,3420C,TEAO,F1
Made To Order
No
Medium Description
Direct Drive Fan, 0.5 HP, 1200 RPM, Frame Size 48Yz, Standard Mounting, 1 Phase, TEAO Enclosure, 115 V, 60 Hz (YPC364A)
Minimum Order Quantity
1 piece
Motor Base Type
Yoke Pedestal
Motor Frame Size
48YZ
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
1
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.5 Hp
Power Factor
93 %
Product Name
Direct Drive Fan
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
27 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.4 A
Rated Efficiency
68 %
Rated Speed
1075 r/min
RoHS Information
RoHS Compliant
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.5 in
Short Description
0.5 HP, 1200 RPM, Frame Size 48Yz, Standard, 1 PH, TEAO, 115 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
115 V
Feature → Direct-drive design with TEAO enclosure reduces mechanical complexity, belt wear, and maintenance costs, while shrinking the overall footprint for compact equipment. Business Impact → Lower lifecycle costs, improved reliability, and easier servicing in tight spaces. Application → Direct-drive cooling fans in OEM machinery and small industrial lines. Feature → 0.5 HP, 115 V, 1PH, 60 Hz with 48YZ frame provides straightforward integration with standard power and standard mounting footprints. Business Impact → Faster installation, reduced wiring errors, and compatibility with common panel layouts. Application → Small motors in conveyors, fans, and process equipment. Feature → Rated Speed 1075 r/min (Synchronous 1200 r/min) with 6P, single-speed operation ensures stable airflow. Business Impact → Consistent process cooling and predictable performance under varying load. Application → Air handling and cooling fans in manufacturing and packaging lines. Feature → RoHS compliant and CSA/UR certified with NEMA standards alignment enhances regulatory compliance and global sourcing. Business Impact → Minimized risk, easier cross-border procurement, and acceptance in regulated sectors like food, pharma, and electronics. Application → Global OEM deployments and service contracts. Feature → TEAO enclosure, ambient rating 40 °C, and 1-phase direct-on-line starting simplify installation and operation. Business Impact → Reduced cooling requirements, fewer components, and immediate startup without external soft starters. Application → Industrial environments with moderate ambient temperatures and straightforward drive systems. Feature → Weight 27 lb, Frame 48YZ, Mounting Horizontal (F1) with Yoke Pedestal base supports robust installation. Business Impact → Strong mounting stability reduces vibration and noise, extending bearing life. Application → Direct-drive fan assemblies in compact enclosures and control panels.
