ABB 7BZDM3587T AC Inverter / Vector Duty - IE3
Part Number: 7BZDM3587T
Quick Summary
ABB 7BZDM3587T is an AC inverter / vector duty drive for 2 HP, three-phase applications. Engineered to reduce downtime and motor wear, it delivers precise speed control in demanding manufacturing environments. CSA | UR certified with NEMA-compliant components and IE3 premium efficiency help meet regulatory and energy goals. The TEBC enclosure and C-face mounting simplify installation, while dual voltage (230/460 V) supports flexible plant-wide integration. This drive helps manufacturers optimize conveyors, pumps, and machine tools with reliable performance and lower operating costs.
Product Information
Extended Description
7BZDM3587T ABB: AC Inverter / Vector Duty 2 Hp 230 V (ZDM3587T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1760RPM,3PH,60HZ,145TC,0526M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM3587T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
05LYE535: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
145
Frequency (f)
60 Hz
Global Commercial Alias
ZDM3587T
Gross Volume
3590.443 in³
Gross Weight
75 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
2HP,1760RPM,3PH,60HZ,145TC,0526M,TEBC,F1
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
AC Inverter / Vector Duty, 2 HP, 1800 RPM, Frame Size 145Tc, C-Face Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (ZDM3587T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
76 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
75 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.6 A | 2.8 A
Rated Efficiency
86.50 %
Rated Speed
1760 r/min
Replaced Product ID (OLD)
7B05E535X509G2
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.88 in
Short Description
2 HP, 1800 RPM, Frame Size 145Tc, C-Face, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The vector-duty AC inverter delivers precise torque control and smooth ramping, reducing mechanical stress and extending motor life, which translates to lower maintenance costs in high-cycle environments. Application: ideal for conveyors, feeders, and packaging lines where consistent throughput matters. Feature → Business Impact → Application: Dual voltage capability (230/460 V) enables a single drive to span multiple plants or line setups, simplifying stocking and lowering total cost of ownership. Application: retrofit projects and cross-site deployments across 60 Hz networks. Feature → Business Impact → Application: TEBC enclosure with C-face mounting provides rugged protection in dirty or dusty facilities and eases installation in tight spaces, reducing commissioning time. Application: food & beverage, material handling, and process automation. Feature → Business Impact → Application: IE3 premium efficiency and CSA | UR certification ensure regulatory compliance and energy savings, supporting green manufacturing initiatives. Application: pump stations, fans, and motor-control centers. Feature → Business Impact → Application: Frame 145TC and 4-pole configuration deliver predictable performance with a compact footprint, enabling easier panel integration and space optimization. Application: machine tools and packaging machinery. Feature → Business Impact → Application: 2 HP, 1760 r/min nominal speed with 60 Hz operation provides reliable start-stop response for line start/stop routines. Application: textile machinery, mixers, and automated sorting systems.
Get a Quick Quote for a ABB 7BZDM3587T
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BZDM3587T?
Enquire Now
FAQs
Yes. The 7BZDM3587T supports 230 V / 460 V, 3-phase operation, and features a C-face drive end mounting alongside a TEBC enclosure. Its horizontal mounting option and robust enclosure simplify panel integration and servicing in standard manufacturing environments.
Expect a nominal 1760 r/min speed with 2 HP output, and an efficiency of about 86.5% (IE3). The drive offers a steady power factor around 0.76, supporting efficient operation of 3-phase motors during variable-speed control and load changes.
Yes. The vector-duty capability provides precise torque and speed control ideal for conveyors, pumps, and machine tools. With 60 Hz operation and TEBC protection, it maintains performance under load fluctuations typical of material handling and process pumping.
The unit carries CSA | UR certification and aligns with NEMA standards, plus IE3 premium efficiency. These indicate regulatory compliance, safer electrical integration, and energy savings—crucial for regulated facilities and sustainability goals.
Stock is readily available across multiple warehouses, with lead times listed as 0 days in supplier data, supporting fast deployment. Warranty terms state that warranty returns are required if applicable. The combination of energy efficiency and reliable speed control contributes to faster ROI through reduced energy use and lower maintenance.
