ABB 7BZDM3665T-5 AC Inverter / Vector Duty - CSA UR
Part Number: 7BZDM3665T-5
Quick Summary
AC Inverter / Vector Duty drives deliver precise motor control for 3‑phase industrial processes. The ABB 7BZDM3665T-5 is a 5 HP, 575 V inverter designed for demanding applications such as conveyors, pumps, and fans. If startup surges, inconsistent speeds, or integration challenges slow your line, this model provides a robust, plug‑in solution. With certifications including CSA and UR, plus NEMA-aligned standards and IE3 efficiency, you can trust safe, compliant operation. Its 5 HP rating, 575 V input, and 184TC frame translate to reliable performance while streamlining procurement and maintenance for US‑based manufacturers.
Product Information
Extended Description
7BZDM3665T-5 ABB: AC Inverter / Vector Duty 5 Hp 575 V (ZDM3665T-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1750RPM,3PH,60HZ,184TC,0640M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM3665T-5
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
06LYF552: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
184
Frequency (f)
60 Hz
Global Commercial Alias
ZDM3665T-5
Gross Volume
7192.91 in³
Gross Weight
125 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
5HP,1750RPM,3PH,60HZ,184TC,0640M,TEBC,F1
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
AC Inverter / Vector Duty, 5 HP, 1800 RPM, Frame Size 184Tc, C-Face Mounting, 3 Phase, TEBC Enclosure, 575 V, 60 Hz (ZDM3665T-5)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
80 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Weight
125 lb
Product Net Width
16.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
5.2 A
Rated Efficiency
90.20 %
Rated Speed
1750 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.13 in
Short Description
5 HP, 1800 RPM, Frame Size 184Tc, C-Face, 3 PH, TEBC, 575 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
575 V
Feature → 5 HP, 575 V, 60 Hz inverter drive with vector duty capability. Business Impact → Delivers smooth torque control and energy efficiency for dynamic loads, reducing process variation and energy waste. Application → Suitable for pumps, conveyors, and fans in automation lines requiring precise speed control. Feature → TEBC enclosure with C‑Face mounting. Business Impact → Enhances protection in harsh environments and enables straightforward retrofit or retrofit‑friendly installations. Application → Ideal for factory floors with dust, humidity, or temperature variability. Feature → Direct On Line starting compatibility. Business Impact → Simplifies integration with legacy motors while preserving motor protection and starting reliability. Application → Retrofit projects and modernization of existing plants. Feature → Frame 184TC, shaft 1.13 in and foot‑mounted base. Business Impact → Facilitates standard mounting in common machine frames, reducing enclosure changes and ensuring alignment. Application → Replacements and upgrades in rolling mills, mixers, and material handling systems. Feature → IE3 efficiency of 90.2% and overall energy savings. Business Impact → Lowers operating costs and helps meet energy regulations and sustainability targets. Application → Continuous duty drives in high‑duty cycles. Feature → Stocked At Multiple Warehouses (US and international). Business Impact → Shortens lead times, minimizes project downtime, and supports just‑in‑time procurement. Application → Critical for OEMs and integrators delivering on tight schedules.
Get a Quick Quote for a ABB 7BZDM3665T-5
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7BZDM3665T-5?
Enquire Now
FAQs
This drive is rated for 575 V three‑phase 60 Hz power and comes in a 184TC frame with TEBC enclosure and C‑Face mounting. It supports foot mounting for straightforward integration with standard machine bases. Ensure your panel provides the correct supply, proper wiring, and that the motor to be driven matches the 5 HP rating for best results.
Key specs include 5 HP nominal output, 1750 r/min rated speed (with a 1800 r/min synchronous speed), 60 Hz, and a rated current of 5.2 A. Efficiency is IE3 class at about 90.2%. These factors translate to smooth speed control, reduced energy usage, and reliable operation for dynamic loads in conveyors and pumps.
Yes. The vector duty capability, precise speed control, and TEBC enclosure make it suitable for conveyors, pumps, and fans in demanding packaging and process lines. Its 575 V input supports North American facilities, and the 3‑phase control aligns with common industrial drives used in continuous production environments.
The drive carries CSA and UR certifications, with NEMA standards alignment. These certifications indicate compliance with safety and performance requirements for industrial equipment in North America, helping simplify supplier qualification, ensure safety in harsh environments, and support regulatory adherence in regulated sectors.
ABB 7BZDM3665T-5 ships with favorable stock levels across multiple warehouses, enabling rapid deployment and reduced downtime. The solid IE3 efficiency and dependable DOL starting compatibility contribute to lower operating costs and higher throughput. For maintenance, standard motor drive practices apply, with the warranty terms described in supplier documentation.
