ABB 7BZDM3770T-5 AC Inverter / Vector Duty - CSA UR
Part Number: 7BZDM3770T-5
Quick Summary
ABB 7BZDM3770T-5 is an AC inverter designed for vector-duty motor control in demanding industrial applications. It delivers precise speed and torque for 3-phase motors used in conveyors, pumps, and processing lines. Operators seeking reliable speed control face downtime, compatibility challenges, and energy inefficiencies. This drive addresses those pain points with robust protection, fast availability, and proven performance. With CSA and UR listings, a TEBC enclosure, and a 575 V rating, it meets essential safety and environmental requirements. The rugged 213TC frame, C-face mounting, and IE3 efficiency support lower maintenance costs and predictable performance, delivering tangible business value for engineering and procurement teams.
Product Information
Extended Description
7BZDM3770T-5 ABB: AC Inverter / Vector Duty 7.5 Hp 575 V (ZDM3770T-5)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
38M 4P TEBC HOR 213TC T'STATS VECTO
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6307, Ball
Bearing NDE
6206
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM3770T-5
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
07LYD515: Dimension Sheet
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
213
Frequency (f)
60 Hz
Global Commercial Alias
ZDM3770T-5
Gross Volume
9144.346 in³
Gross Weight
170 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
38M 4P TEBC HOR 213TC T'STATS VECTOR
Made To Order
No
Maximum Speed
4000 r/min
Medium Description
AC Inverter / Vector Duty, 7.5 HP, 1800 RPM, Frame Size 213Tc, C-Face Mounting, 3 Phase, TEBC Enclosure, 575 V, 60 Hz (ZDM3770T-5)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
213TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
7.5 Hp
Power Factor
81 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
28.625 in
Product Net Height
17.625 in
Product Net Weight
170 lb
Product Net Width
18.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
7.5 A
Rated Efficiency
91.70 %
Rated Speed
1770 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.38 in
Short Description
7.5 HP, 1800 RPM, Frame Size 213Tc, C-Face, 3 PH, TEBC, 575 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
575 V
7.5 HP output at 575 V, 3-phase, 60 Hz vector-duty drive provides precise torque control for conveyors, pumps, and automated tooling. Responsive acceleration and smooth deceleration reduce mechanical stress, extend bearing life, and minimize process oscillations under dynamic loads. In packaging lines and material-handling systems, this level of control translates into consistent product quality and higher line uptime. The built-in vector drive capability also supports advanced motor control strategies without requiring external controllers, simplifying system architecture. 213TC frame, TEBC enclosure, and C-Face drive end flange enable quick retrofits and straightforward mechanical alignment with existing motors. The foot-mounted configuration supports horizontal installation in compact enclosures, while TEBC protection delivers ingress resistance in dusty or humid factories. The combination reduces commissioning risk and shortens time-to-first-run, essential for capital-intensive projects or greenfield deployments. IE3 efficiency at 91.7% and a rated current of 7.5 A drive energy savings across typical duty cycles. This translates to lower operating costs in high-duty conveyors and pumps, improved power factor, and reduced heat generation in control panels. With 1800 r/min synchronous speed and 1770 r/min rated speed, you get precise speed matching to your process without oversizing drives. Zero-day lead time and stocking across multiple warehouses enable confident project planning and on-time commissioning. Direct On Line startup minimizes soft-start requirements, while the 4-pole design keeps torque characteristics predictable. These attributes combine to shorten project cycles and reduce carrying costs for procurement teams. Industry-standard compatibility with NEMA guidelines and a robust 575 V rating help ensure regulatory alignment and long service life. The 1.38 in shaft diameter and 213TC frame simplify coupling selection and spare-parts strategy, while a 3-phase, 4-pole configuration aligns with common factory automation architectures. In short, ABB's 7BZDM3770T-5 offers reliable control, energy efficiency, and rapid deployment for demanding manufacturing environments.
