ABB 7BZDM4100T AC Inverter / Vector Duty - TEBC Enclosure
Part Number: 7BZDM4100T
Quick Summary
ABB 7BZDM4100T AC Inverter / Vector Duty delivers precise motor control for 3-phase industrial drives. This vector-duty drive is engineered to optimize performance on 60 Hz networks with 230/460 V supplies, delivering smooth starting, accurate speed control, and reliable operation in demanding environments. For engineers, common pain points include energy waste, thermal overload, and inconsistent ramp profiles that disrupt production lines. The unit carries CSA and UR certifications and supports NEMA-style TEBC enclosures, aligning with global safety and reliability standards. With a compact footprint and fast availability across multiple warehouses, it supports quick deployment, reduced downtime, and predictable total cost of ownership, while integrating with existing automation stacks.
Product Information
Extended Description
7BZDM4100T ABB: AC Inverter / Vector Duty 15 Hp 230 V (ZDM4100T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
46M 6P TEBC HOR 284T TSTATS VECTOR
Ambient Temperature
40 °C
Base Speed
1200 r/min
Bearing
6311, Ball
Bearing NDE
6309
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM4100T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
10LYT004: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
284
Frequency (f)
60 Hz
Global Commercial Alias
ZDM4100T
Gross Volume
27984 inÂł
Gross Weight
412 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
46M 6P TEBC HOR 284T TSTATS VECTOR
Made To Order
No
Maximum Speed
1800 r/min
Medium Description
AC Inverter / Vector Duty, 15 HP, 1200 RPM, Frame Size 284T, Standard Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (ZDM4100T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
284T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
15 Hp
Power Factor
73 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
44 in
Product Net Height
24 in
Product Net Weight
412 lb
Product Net Width
26.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
42 A | 21 A
Rated Efficiency
91.70 %
Rated Speed
1175 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.88 in
Short Description
15 HP, 1200 RPM, Frame Size 284T, Standard, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature: 15 HP, 230/460 V, 3-phase vector drive. Business impact: enhanced torque control and smoother acceleration, reducing mechanical wear and process variance. Application: conveyors, pumps, and fans in manufacturing lines benefit from consistent performance. Feature: Premium Efficiency (91.70%). Business impact: lower energy consumption and reduced cooling load, improving overall plant energy intensity. Application: continuous operation in automated lines with tight uptime targets. Feature: TEBC enclosure and 40 °C ambient rating. Business impact: rugged reliability in harsh environments and extended service life, minimizing enclosure-related faults. Application: outdoor or workshop floors with limited climate control. Feature: Frame 284T, foot-mounted, 44 in length, 26.5 in width, 24 in height. Business impact: compact footprint enables easy retrofits and space-conscious installations. Application: panel integrations within existing ABB/Baldor-Reliance ecosystems. Feature: Direct On Line starting and 3-phase, 60 Hz operation. Business impact: simplified commissioning and fast throughput, reducing startup time. Application: new line builds and upgrade projects. The combination of dual rated current (42 A / 21 A) and shaft diameter 1.88 in further supports precise motor matching and upgrade paths, while compatibility with 230/460 V networks and 284T frame size addresses common industrial applications across multiple sectors.
