ABB 7BZDM4102T AC Inverter - Premium Efficiency
Part Number: 7BZDM4102T
Quick Summary
ABB 7BZDM4102T AC Inverter is a vector-duty drive engineered for precise motor control in heavy industry applications such as conveyors, pumps, and fans. The device addresses common downtime and performance challenges by delivering smooth starting, reliable protection, and adaptable speed control across 60 Hz systems. With CSA and UR certifications, a NEMA-design compliant TEBC enclosure, and a 40 °C ambient rating, this inverter is built for harsh factory environments. Its 286T frame, 3-phase 230/460 V capability, and direct-on-line start simplify integration with existing electrical architectures. Operational reliability translates to reduced maintenance and predictable throughput, while the compact footprint supports easier panel space utilization and faster installation in retrofit projects.
Product Information
Extended Description
7BZDM4102T ABB: AC Inverter / Vector Duty 20 Hp 230 V (ZDM4102T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
54M 6P TEBC HOR 286T TSTATS VECTOR
Ambient Temperature
40 °C
Base Speed
1200 r/min
Bearing
6311, Ball
Bearing NDE
6309
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM4102T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
10LYT004: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
286
Frequency (f)
60 Hz
Global Commercial Alias
ZDM4102T
Gross Volume
24317.313 inÂł
Gross Weight
462 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
54M 6P TEBC HOR 286T TSTATS VECTOR
Made To Order
No
Maximum Speed
1800 r/min
Medium Description
AC Inverter / Vector Duty, 20 HP, 1200 RPM, Frame Size 286T, Standard Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (ZDM4102T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
286T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
20 Hp
Power Factor
77 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
43.25 in
Product Net Height
21.625 in
Product Net Weight
462 lb
Product Net Width
26 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
54 A | 27 A
Rated Efficiency
91.70 %
Rated Speed
1180 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.88 in
Short Description
20 HP, 1200 RPM, Frame Size 286T, Standard, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature: 20 HP AC Inverter / Vector Duty with 1200 r/min base speed and 3-phase 230/460 V capability. Business Impact: enables accurate torque and speed control, improving process stability and reducing energy draw. Application: ideal for belt conveyors, pump-and-fan units, and mixers in continuous-operation lines. Feature: TEBC enclosure, ambient rating 40 °C, and NEMA design compatibility. Business Impact: rugged protection and easier installation in machine rooms, reducing environmental risk and repair time. Application: suitable for manufacturing floors and outdoor-rated panels. Feature: Frame 286T with a nominal 54 A current and 1200 r/min synchronous speed. Business Impact: supports reliable coupling to standard motors, improved start-up performance, and consistent processing speeds. Application: heavy-duty industrial drives and OEM integrations. Feature: Stocked at multiple warehouses with 0 day lead time. Business Impact: minimizes downtime, accelerates project timelines, and simplifies spare-parts strategy. Application: rapid deployment in plant upgrades and new line builds. Feature: Direct On Line starting, 3-phase input, and 230/460 V capability. Business Impact: fast commissioning, reduced soft-start requirements, and lower control panel complexity. Application: line-starts for conveyors, pumps, and fans in busy production environments.
