ABB 7BZDM4104T AC Inverter / Vector Duty - TEBC Enclosure
Part Number: 7BZDM4104T
Quick Summary
ABB 7BZDM4104T AC Inverter / Vector Duty is designed for motor control in 3-phase drives, ideal for conveyors, mixers, and pumps. This drive addresses common challenges like inrush current, torque fluctuation, and energy waste by delivering smooth startup, robust vector control, and programmable protection. It carries CSA and UR certifications, a TEBC enclosure, and operates at 60 Hz with 230/460 V ratings to support global compliance. By combining high efficiency, reliable performance, and a compact 286T frame, this solution reduces downtime, lowers lifetime energy cost, and accelerates automation ROI for heavy-duty applications in manufacturing and material handling.
Product Information
Extended Description
7BZDM4104T ABB: AC Inverter / Vector Duty 30 Hp 230 V (ZDM4104T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
56M 4P TEBC HOR 286T T'STATS VECTO
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6311, Ball
Bearing NDE
6309
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM4104T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
10LYT004: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
286
Frequency (f)
60 Hz
Global Commercial Alias
ZDM4104T
Gross Volume
24317.313 in³
Gross Weight
445 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
56M 4P TEBC HOR 286T T'STATS VECTOR
Made To Order
No
Maximum Speed
2700 r/min
Medium Description
AC Inverter / Vector Duty, 30 HP, 1800 RPM, Frame Size 286T, Standard Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (ZDM4104T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
286T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
30 Hp
Power Factor
80 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
43.25 in
Product Net Height
21.625 in
Product Net Weight
445 lb
Product Net Width
26 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
76 A | 38 A
Rated Efficiency
93.60 %
Rated Speed
1760 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.88 in
Short Description
30 HP, 1800 RPM, Frame Size 286T, Standard, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature: Vector Duty control for 30 Hp at 230/460 V with 60 Hz operation. Business Impact: Precise torque, smooth acceleration, and reduced mechanical stress. Application: Conveyors, mixers, and pumps where consistent load handling is critical. The result is improved process stability and longer motor life. Feature: TEBC enclosure and NEMA design considerations. Business Impact: Rugged protection against dust, humidity, and heat in harsh factory floors. Application: Heavy-duty line equipment in food, packaging, and material handling. This reduces maintenance events and extends uptime. Feature: Premium Efficiency performance. Business Impact: Lower energy consumption and cooler operation, enabling cost savings on running hours. Application: Continuous duty drives in water treatment, HVAC, and industrial pumping. Feature: Direct On Line starting and simple integration. Business Impact: Faster commissioning, reduced installation risk, and lower starter hardware costs. Application: Retrofit projects and new machine builds with minimal downtime. Feature: Multi-voltage and mechanical compatibility (230/460 V, frame 286T, foot-mounted). Business Impact: Flexible deployment across global plants with standard mounting and straightforward alignment. Application: Global manufacturing networks requiring consistent drive performance with easy spare-part planning. Insight: Stocked at multiple warehouses with 0-day lead time, aiding rapid project ramp-ups and just-in-time procurement for maintenance teams.
