ABB 7BZDM4111T AC Inverter / Vector Duty - CSA UR
Part Number: 7BZDM4111T
Quick Summary
ABB 7BZDM4111T AC inverter is a vector-duty drive designed for precise 3-phase motor control in heavy-load applications such as conveyors and pumps. This model addresses common pain points like startup surges, energy waste, and wear on mechanicals by delivering smooth acceleration and reliable operation. It carries CSA and UR certifications and aligns with NEMA design concepts, while maintaining IE3 premium efficiency to support lower operating costs. With stock available across multiple warehouses and a 0-day lead time, it enables faster project timelines and predictable maintenance planning. Engineered for TEBC enclosure, 324T frame, 230/460 V, and 60 Hz, it integrates smoothly into established automation architectures and ABB drive ecosystems.
Product Information
Extended Description
7BZDM4111T ABB: AC Inverter / Vector Duty 25 Hp 230 V (ZDM4111T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
60M 6P TEBC HOR 324T VECTOR TSTATS
Ambient Temperature
40 °C
Base Speed
1200 r/min
Bearing
6312, Ball
Bearing NDE
6311
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM4111T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
12LYT107: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
324
Frequency (f)
60 Hz
Global Commercial Alias
ZDM4111T
Gross Volume
26312 in³
Gross Weight
605 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
60M 6P TEBC HOR 324T VECTOR TSTATS
Made To Order
No
Maximum Speed
3900 r/min
Medium Description
AC Inverter / Vector Duty, 25 HP, 1200 RPM, Frame Size 324T, Standard Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (ZDM4111T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
324T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
25 Hp
Power Factor
79 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
44 in
Product Net Height
23 in
Product Net Weight
605 lb
Product Net Width
26 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
63 A | 32 A
Rated Efficiency
93 %
Rated Speed
1180 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
2.13 in
Short Description
25 HP, 1200 RPM, Frame Size 324T, Standard, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1200 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: 25 HP output at 1200 r/min makes this drive well-suited for mid-sized conveyors and pumps, delivering robust torque without excessive heat or wear. This translates to improved process stability and reduced maintenance costs in continuous operation scenarios such as material handling and water treatment. Feature → Business Impact → Application: 230/460 V and 60 Hz compatibility provides flexible deployment across global sites, simplifying procurement and minimizing spare-part inventories for multi-site automation projects. Feature → Business Impact → Application: TEBC enclosure with a 324T frame enables rugged installation in demanding environments, ensuring longer service life and easier retrofits for legacy systems in packaging lines and HVAC networks. Feature → Business Impact → Application: Direct On Line starting reduces wiring complexity and startup transients, supporting quick commissioning and lowered shop-floor downtime in industri al automation contexts. Feature → Business Impact → Application: IE3 efficiency, 93% rated, lowers energy losses and operating costs, delivering measurable ROI for continuous-process industries such as pumping stations and material handling. Feature → Business Impact → Application: Ball bearings (6312) and NDE bearing (6311) improve reliability under high-load conditions, beneficial for long-run operations in steel, mining, and cement sectors. Feature → Business Impact → Application: Stocked at multiple warehouses with 0-day lead time shortens procurement cycles, aiding project schedules and service contracts for system integrators and OEMs.
