ABB 7BZDM4115T AC Inverter / Vector Duty - CSA UR
Part Number: 7BZDM4115T
Quick Summary
AC Inverter / Vector Duty ABB 7BZDM4115T delivers precise drive control for 50 HP motors in demanding industrial automation environments. This drive reduces startup surges, energy waste, and thermal stress on motors by offering vector control and soft-start capabilities. Key certifications and standards include CSA/UR safety listings, NEMA design compliance, and TEBC enclosure suitability for harsh industrial environments. Designed for 60 Hz, 230/460 V three-phase systems, the drive integrates with existing PLCs and HMI platforms to streamline commissioning. With 50 HP capacity, 326T frame, and 1775 rpm nominal speed, it delivers reliable performance across conveyors, pumps, and fans. Stocked across major warehouses with zero-day lead time, it supports fast procurement and uptime for critical production lines.
Product Information
Extended Description
7BZDM4115T ABB: AC Inverter / Vector Duty 50 Hp 230 V (ZDM4115T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
50HP,1775RPM,3PH,60HZ,326T,1272M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6312, Ball
Bearing NDE
6311
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDM4115T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
12LYT107: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEBC
Frame Material
Iron
Frame Size
326
Frequency (f)
60 Hz
Global Commercial Alias
ZDM4115T
Gross Volume
24317.313 inÂł
Gross Weight
631 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
50HP,1775RPM,3PH,60HZ,326T,1272M,TEBC,F1
Made To Order
No
Maximum Speed
3900 r/min
Medium Description
AC Inverter / Vector Duty, 50 HP, 1800 RPM, Frame Size 326T, Standard Mounting, 3 Phase, TEBC Enclosure, 230/460 V, 60 Hz (ZDM4115T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
326T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
A
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
50 Hp
Power Factor
85 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
43.25 in
Product Net Height
21.625 in
Product Net Weight
631 lb
Product Net Width
26 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
116 A | 58 A
Rated Efficiency
94.50 %
Rated Speed
1775 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
2.13 in
Short Description
50 HP, 1800 RPM, Frame Size 326T, Standard, 3 PH, TEBC, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
50 HP output in a 326T frame for 230/460 V, 60 Hz three-phase operation enables precise motor control with a compact footprint. This translates to smaller control cabinets and easier retrofits, reducing installation time and cooling needs. Ideal for conveyors, pumps, and fans across manufacturing lines. Direct On Line starting simplifies commissioning and reduces external soft-start hardware needs. Lower installation costs and reduced startup surge risk translate to increased line uptime and safer ramp-up in high-speed packaging lines. Suitable for high-cycle conveyors and motors in assembly and material handling applications. Premium efficiency (94.50%) and insulation class H improve energy performance and durability. Lower energy costs and reduced cooling requirements complement long-term maintenance planning, while the TEBC enclosure protects critical components in dirty or humid environments. This is a strong fit for continuous-duty drives in manufacturing facilities. TEBC enclosure coupled with NEMA design code A provides robust protection and reliability. The rugged frame size and foot-mount option simplify installation and service, enabling faster upgrades in existing equipment. Applications include general-purpose industrial drives across metal fabrication, food & beverage, and packaging lines. Stocking in multiple warehouses with zero-day lead time minimizes procurement risk and downtime during upgrades. The capability to source from US and international locations supports just-in-time projects and global rollouts. Integration with ABB/Baldor-Reliance components also reduces spare-part complexity and warranty coverage concerns. CSA/UR safety certifications and alignment with NEMA standards reassure compliance teams and end users. The combination of high efficiency, rugged enclosure, and fast availability helps drive total cost of ownership down while improving process reliability. This makes the 7BZDM4115T a suitable choice for demanding industrial drives programs.
