ABB 7BZDNM3581T AC Inverter / Vector Duty - CSA UR Certified
Part Number: 7BZDNM3581T
Quick Summary
ABB 7BZDNM3581T AC inverter is a vector-duty drive designed to control 1 HP motors in demanding industrial applications. It delivers smooth speed control for conveyors, pumps, and machine tools while maintaining reliability in 230/460 V, 60 Hz networks. The main pain points addressed are downtime from improper drive selection, long procurement lead times, and challenging integration with existing systems. With stock in multiple regional warehouses, it enables faster procurement and quicker rollout. This model carries CSA and UR certifications and IE3 premium efficiency, plus a rugged TENV enclosure suitable for harsh environments. Its compact footprint, C-face mounting, and DOL starting capability align with standard NEMA B design and diverse OEM needs, delivering clear total-cost-of-ownership advantages.
Product Information
Extended Description
7BZDNM3581T ABB: AC Inverter / Vector Duty 1 Hp 230 V (ZDNM3581T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,1770RPM,3PH,60HZ,143TC,0522M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDNM3581T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Dimension Diagram
05LYE532
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Iron
Frame Size
143
Frequency (f)
60 Hz
Global Commercial Alias
ZDNM3581T
Gross Volume
3496.049 in³
Gross Weight
59 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
1HP,1770RPM,3PH,60HZ,143TC,0522M,TENV,F1
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
AC Inverter / Vector Duty, 1 HP, 1800 RPM, Frame Size 143Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (ZDNM3581T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
143TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
68 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
59 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.2 A | 1.6 A
Rated Efficiency
85.50 %
Rated Speed
1770 r/min
Replaced Product ID (OLD)
7B05E532X545G1
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.88 in
Short Description
1 HP, 1800 RPM, Frame Size 143Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Vector Duty control enables precise speed and torque shaping, reducing motor wear and helping maintain consistent product throughput on conveyors and packaging lines. This translates to lower maintenance costs and improved line reliability in high-cycle operations. The 230/460 V, 3-phase, 60 Hz compatibility ensures seamless integration with existing plant power, enabling quick replacement and faster commissioning for mixed fleets. IE3 Premium Efficiency and a TENV enclosure deliver energy savings and robust protection in demanding environments, supporting compliance goals and longer motor life on pumps and fans. The 143TC frame with 4-pole design provides a familiar footprint for standard motors, simplifying retrofits and spare-part planning while enabling reliable DOL starting for smooth ramp-up on loading equipment. Stock availability across multiple warehouses reduces downtime and accelerates project timelines for OEMs and service teams. The C-face mounting, foot-mounted configuration and 0-day lead time capability offer installation flexibility and faster deployment across shop floors and field installations.
