ABB 7BZDNM3661T AC Inverter / Vector Duty - CSA UR
Part Number: 7BZDNM3661T
Quick Summary
ABB 7BZDNM3661T AC Inverter / Vector Duty is designed to drive 3 HP motors with precise vector control for demanding industrial environments. This model delivers smooth start-up and reliable speed regulation for 230/460 V, 60 Hz, three-phase systems. Sourcing a compact, warranty-backed inverter that fits a 184TC frame and C-Face mounting is a common challenge, and this product meets that need. With CSA and UR certifications and alignment to NEMA standards, it supports safe panel integration and regulatory compliance. The TENV enclosure and robust insulation reduce downtime in hot manufacturing settings, while enabling consistent operation. In practice, engineers gain faster commissioning, lower total cost of ownership, and improved process repeatability across motor-driven applications.
Product Information
Extended Description
7BZDNM3661T ABB: AC Inverter / Vector Duty 3 Hp 230 V (ZDNM3661T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,1760RPM,3PH,60HZ,184TC,0632M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDNM3661T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
06LYF550
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Energy Efficiency (NEMA 12-11)
Electrical Data
Enclosure Type
TENV
Frame Material
Iron
Frame Size
184
Frequency (f)
60 Hz
Global Commercial Alias
ZDNM3661T
Gross Volume
5274.135 in³
Gross Weight
101 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
3HP,1760RPM,3PH,60HZ,184TC,0632M,TENV,F1
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
AC Inverter / Vector Duty, 3 HP, 1800 RPM, Frame Size 184Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (ZDNM3661T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
76 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
101 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
8.4 A | 4.2 A
Rated Efficiency
88.50 %
Rated Speed
1755 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.13 in
Short Description
3 HP, 1800 RPM, Frame Size 184Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The 3 HP inverter motor delivers strong vector control for precise speed regulation, improving process accuracy and reducing production variances in conveyors and machine tools. This translates to measurable efficiency gains and lower energy consumption, supported by an 88.5% rated efficiency and 76% power factor; ideal for high-throughput material handling in packaging lines. Feature → Business Impact → Application: The 184TC frame with C-Face mounting simplifies retrofit and installation, enabling quick integration into existing equipment racks and minimizing downtime during commissioning in CNC machines and pumps. Feature → Business Impact → Application: The 60 Hz, 230 V / 460 V, 3-phase design, coupled with a direct-on-line starting method, provides straightforward control upgrades for legacy systems, reducing upfront wiring complexity and enabling scalable controls for automated lines. Feature → Business Impact → Application: The TENV enclosure and insulation class H enable operation in elevated ambient temperatures up to 40 °C, supporting reliability in warm factory floors and reducing unscheduled maintenance for heat-sensitive drives. Feature → Business Impact → Application: The compact footprint (Product Net Width 16.125 in, Length 21.625 in, Height 15.125 in) allows installation in tight control cabinets and on machine frames, improving overall footprint efficiency in packaging and bottling lines. Feature → Business Impact → Application: CSA / UR certification and adherence to NEMA standards simplify compliance audits and supplier qualification programs, helping procurement reduce risk when purchasing motor drives for critical equipment such as mixers, grinders, and centrifuges. This combination of performance, robustness, and regulatory alignment is especially valuable for industries requiring consistent uptime and predictable total cost of ownership.
