ABB 7BZDNM3669T AC Inverter / Vector Duty - CSA UR
Part Number: 7BZDNM3669T
Quick Summary
ABB 7BZDNM3669T AC Inverter / Vector Duty provides precise motor control for 3-phase systems across manufacturing, packaging, and material handling. This drive is designed to minimize downtime with immediate availability and stock across multiple warehouses, helping maintenance teams reduce emergency采购 costs and shorten procurement cycles. Certifications include CSA | UR recognition and compliance with NEMA standards, reinforcing safety and reliability in harsh industrial environments. The unit supports 230/460 V at 60 Hz with continuous-duty performance, delivering consistent torque and energy efficiency. Its compact footprint, standard 182TC frame, and C-face mounting streamline panel integration while enabling scalable automation in evolving production lines. This combination drives lower total cost of ownership and improved uptime for industrial automation projects.
Product Information
Extended Description
7BZDNM3669T ABB: AC Inverter / Vector Duty 2 Hp 230 V (ZDNM3669T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1760RPM,3PH,60HZ,182TC,0624M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDNM3669T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
06LYF550
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Iron
Frame Size
182
Frequency (f)
60 Hz
Global Commercial Alias
ZDNM3669T
Gross Volume
5274.135 in³
Gross Weight
95 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
2HP,1760RPM,3PH,60HZ,182TC,0624M,TENV,F1
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
AC Inverter / Vector Duty, 2 HP, 1800 RPM, Frame Size 182Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (ZDNM3669T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
182TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
71 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
95 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
6 A | 3 A
Rated Efficiency
88.50 %
Rated Speed
1760 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.13 in
Short Description
2 HP, 1800 RPM, Frame Size 182Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: The 2 HP, 1760 RPM rated output at 230/460 V, 60 Hz, 3-phase capability enables precise motor control for conveyors, pumps, and fans, reducing torque ripple and improving process stability. This translates to lower maintenance cycles and higher process reliability in continuous duty applications, especially in packaging lines and material handling. Feature → Business Impact → Application: Frame size 182TC with C-Face mounting and foot-mounted configuration simplifies installation and retrofit projects, cutting assembly time by aligning with standard motor interfaces and reducing mounting intricacies on busy OEM lines. Feature → Business Impact → Application: Totally Enclosed Non-Ventilated (TENV) enclosure rated for 40 °C ambient conditions protects sensitive electronics on factory floors, increasing uptime in hot or dusty environments and enabling outdoor panel installations where climate control is limited. Feature → Business Impact → Application: Premium Efficiency (NEMA 12-12) and insulation class H deliver measurable energy savings and thermal margin, supporting energy management initiatives and compliant operating budgets in large-scale manufacturing. Feature → Business Impact → Application: Direct On Line starting and 0 day lead time availability minimize start-up delays and spare-part staging, helping procurement teams maintain lean inventories while ensuring rapid field replacements in automotive, food & beverage, and plastics sectors. Feature → Business Impact → Application: 3-phase, 60 Hz compatibility with 230/460 V power systems enables seamless integration into existing plant electrical infrastructure, reducing wiring complexity and enabling plug-and-play deployment in new lines or retrofits for industrial automation projects.
