ABB 7BZDNM3767T AC Inverter - 5HP 60Hz CSA/UR
Part Number: 7BZDNM3767T
Quick Summary
AC Inverter / Vector Duty drives 3‑phase motors for precise speed control in industrial automation and process equipment. Users often contend with startup surges, energy waste, and unplanned downtime that erode productivity and maintenance budgets. This ABB drive carries CSA and UR certifications, a NEMA Premium Efficiency profile, and a TENV enclosure, supporting reliable operation across demanding environments. Designed for 60 Hz systems with 230/460 V options, it integrates smoothly with standard 213TC frame motors and C‑face mounting for quick retrofits. Coupled with 5 HP output and vector control, it delivers measurable efficiency gains, reduced torque ripple, and improved motor life—critical for automated conveyors, pumps, and machine tools.
Product Information
Extended Description
7BZDNM3767T ABB: AC Inverter / Vector Duty 5 Hp 230 V (ZDNM3767T)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1765RPM,3PH,60HZ,213TC,0740M,TE
Ambient Temperature
40 °C
Base Speed
1800 r/min
Bearing
6307, Ball
Bearing NDE
6206
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
ZDNM3767T
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Dimension Diagram
07LYJ134
Drive End Flange Type
C-Face
ETIM 7
EC001851 - Electric motor
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TENV
Frame Material
Iron
Frame Size
213
Frequency (f)
60 Hz
Global Commercial Alias
ZDNM3767T
Gross Volume
9144.346 inÂł
Gross Weight
173 lb
IDEA Granular Category Code (IGCC)
1319 >> Inverter motor AC
Insulation Class
H
Invoice Description
5HP,1765RPM,3PH,60HZ,213TC,0740M,TENV,F1
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
AC Inverter / Vector Duty, 5 HP, 1800 RPM, Frame Size 213Tc, C-Face Mounting, 3 Phase, TENV Enclosure, 230/460 V, 60 Hz (ZDNM3767T)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
213TC
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
83 %
Product Name
AC Inverter / Vector Duty
Product Net Depth / Length
28.625 in
Product Net Height
17.625 in
Product Net Weight
173 lb
Product Net Width
18.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
12.4 A | 6.2 A
Rated Efficiency
89.50 %
Rated Speed
1765 r/min
Replaced Product ID (OLD)
7B07J134Y566Z1
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.38 in
Short Description
5 HP, 1800 RPM, Frame Size 213Tc, C-Face, 3 PH, TENV, 230/460 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101106
Voltage Rating
230 V | 460 V
Feature: 5 HP output with 3‑phase, 60 Hz input and 230/460 V options. Business Impact: Enables precise speed control and scalable drive performance across mid‑size automation tasks, reducing energy waste and improving process consistency. Application: Ideal for conveyors, pumps, and machine tools in automated lines. The 60 Hz capability ensures compatibility with standard U.S. grid frequency, while dual voltage support simplifies retrofits. Feature: 213TC frame size with C‑face mounting and foot mounting option. Business Impact: Facilitates rapid installation and seamless integration with existing motor assemblies, lowering retrofit downtime and installation costs. Application: Suitable for horizontal mounting on standard machine frames in factory automation. Feature: TENV enclosure and Insulation Class H. Business Impact: Delivers robust protection in moderate ambient temperatures, extending motor life in manufacturing environments and reducing maintenance cycles. Application: Use in clean, dry plant floors where enclosure protection is required. Feature: Premium efficiency and Direct On Line starting. Business Impact: Improves energy efficiency by up to 89.5% rated efficiency and minimizes inrush during startup, cutting energy costs and enhancing system reliability. Application: conveyors and pumping stations seeking energy savings and reduced electrical stress. Feature: 1765 r/min rated speed, 1800 r/min synchronous speed, and 4‑pole design. Business Impact: Provides stable speed profiles and predictable torque for precise process control, improving product quality. Application: automation tasks requiring consistent velocity control in heavy machinery. Feature: 3‑phase 230/460 V operation with 12.4 A / 6.2 A rated currents and 1.38 in shaft diameter. Business Impact: Supports compatibility with standard motor shafts and wiring schemes, simplifying electrical design and reducing procurement lead time. Application: retrofit projects and new installations in material handling and process lines.
