ABB 7GSP008556R0006 Lighting Contactor - UL E30541
Part Number: 7GSP008556R0006
Quick Summary
Lighting Contactor is a core switching device for three-phase loads used in industrial facilities. ABB's 7GSP008556R0006 provides reliable coil-driven control for large lighting and motor circuits, helping to prevent nuisance trips and arcing. This model carries UL certification (E30541) and aligns with ETIM and eClass classifications to simplify procurement and integration. By coupling a compact 3P design with a 120V coil and 225A heating rating, it delivers robust performance, while open bus wiring supports straightforward installation. For projects prioritizing uptime, standardized cataloging, and easy stocking, this solution offers measurable business value and scalable automation potential.
Product Information
Extended Description
7GSP008556R0006 ABB: 160M Lighting Contactor - Mechanical Held,3Poles,225Amps,120V coil,open bus
Minimum Order Quantity
1 EA
Customs Tariff Number
8536490065
Product Net Width
7.13 in
Product Net Depth / Length
9.5 in
Product Net Height
3.13 in
Product Net Weight
4.5 lb
Number of Poles
3P
Product Name
CR160 Lighting Contactor
Full Load Amps AC Resistance (Heating)
225 A
WEEE B2C / B2B
Business To Business
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
Declaration of Conformity - CCC
No certification needed
Declaration of Conformity - UKCA
No certification needed
UL Certificate
E30541
Package Level 1 Units
1 EA
Package Level 1 Width
8 in
Package Level 1 Depth / Length
10 in
Package Level 1 Height
4 in
Package Level 1 Gross Weight
4.5 lb
ETIM 7
EC000533 - Lighting control system component
ETIM 8
EC000533 - Lighting control system component
ETIM 9
EC000533 - Lighting control system component
eClass
V11.1 : 27111005
UNSPSC
39121529
Feature → Business Impact → Application: 3P, 225 A full-load capability supports high-demand lighting and motor circuits, reducing voltage drop and contact wear while enabling reliable startup in large facilities. This translates to fewer trips and lower maintenance costs in HVAC and manufacturing environments, where dependable control is essential. Feature → Application: 120V coil simplifies integration with common control cabinets and relay logic, enabling faster commissioning and compatibility with existing control architectures in plant automation. This reduces installation time and training requirements for maintenance teams. Feature → Business Impact → Application: Mechanical held design provides secure, maintained contacts during switching events, increasing reliability for relief of peak loads in lighting control and emergency lighting systems. Feature → Open bus architecture facilitates easier wiring and future upgrades, lowering installation labor and enabling rapid re-configuration in evolving electrical rooms. Feature → Compliance and classification: UL E30541 certification and ETIM/eClass alignment improve procurement efficiency and cross-manufacturer compatibility, supporting audit readiness and supplier consolidation for industrial lighting control systems. Feature → Physical and packaging attributes: 4.5 lb weight and compact dimensions streamline cabinet fitment and logistics, reducing shipping costs and enabling tighter panel layouts in industrial facilities.
Get a Quick Quote for a ABB 7GSP008556R0006
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7GSP008556R0006?
Enquire Now
FAQs
The CR160 is a 3-pole, 225 A lighting contactor with a 120 V coil designed for standard panel mounting and open bus wiring. It fits common control cabinets and relays, allowing straightforward integration with existing PLC or relay-based control schemes and minimizing rework during upgrades.
Key specs include three poles (3P), full-load amps AC resistance of 225 A, a 120 V coil, mechanical held contacts, and an open bus design. Net weight is 4.5 lb with compact dimensions (approximately 7.13 in W x 9.5 in D x 3.13 in H).
Yes. The unit carries UL certification E30541, confirming compliant performance for safe operation in industrial environments. It is also cataloged under ETIM and eClass classifications to support consistent product data across procurement systems.
Ideal for three-phase lighting and motor control in industrial facilities, including large lighting arrays, HVAC systems, and auxiliary motors. Its high current rating and robust construction support reliable commissioning in demanding environments.
The mechanical held design reduces arcing during switching, contributing to extended contact life under frequent cycling. Regular inspection of contacts and wiring, plus adherence to enclosure and cooling requirements, helps maintain performance and uptime in ongoing operations.
