7TAA122020R0194
Part Number: 7TAA122020R0194
Product Information
Extended Description
7TAA122020R0194 ABB: Stainless Steel Multi-point Junction Bracket, 4 inch Centers. Includes Terminal Lug, External Tooth Lock Washer, Hex Head Cap Screw, Hex Nut, Base Bracket and Shield Plate.
UPC
783786793181
Country of Origin
United States (US)
Selling Unit of Measure
each
Package Level 1 Units
1 EA
Package Level 1 Width
25.4 mm | 1 in
Package Level 1 Height
25.4 mm | 1 in
Package Level 1 Depth / Length
25.4 mm | 1 in
Application
Suited for Subsurface, Vault or Padmount Applications and can be used for Sectionalizing, Looping, Tapping and Equipment Bypass.
Brand / Label
Elastimold
Connection Type
Push-In
Effective Date
20081124
Material
Stainless Steel Mounting Brackets.
Product Name
Other
Product Type
Multi-Point Junction - Bracket
Special Functions
4 inch Center Spacing.
Standards
ANSI/IEEE Standard 386
Temperature Range
-40 to +65 °C
Data Sheet, Technical Information
J5-X4-6
UNSPSC
26121630
WEEE Category
Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)
1779 >> Cable accessories
