7TAI029860R0041
Part Number: 7TAI029860R0041
Product Information
Extended Description
7TAI029860R0041 ABB: Nylon Insulated Parallel Splice, Length .84 Inches, Width .23 Inches, Wire Range #18-#16 AWG, Color Blue, Copper, Tin Plated, 1,000 Pack
EAN
5414363131960
UPC
786210818092
Country of Origin
United States (US)
Selling Unit of Measure
each
Package Level 1 Units
1000 EA
Package Level 1 Width
114.3 mm | 4.5 in
Package Level 1 Height
76.2 mm | 3 in
Package Level 1 Depth / Length
152.4 mm | 6 in
Package Level 2 Units
5000 EA
Package Level 2 Width
120.65 mm | 4.75 in
Package Level 2 Height
78.74 mm | 3.1 in
Package Level 2 Depth / Length
157.48 mm | 6.2 in
Brand / Label
Sta-Kon
Color
Blue
Effective Date
19670713
Material
Copper
Product Name
Terminals, electrical splices and electr ical couplings; wafer probers
Product Type
Nylon Insulated Parallel Splice
Special Functions
Wires are laid side by side in the connector, and the splice connection is complete in one crimp.
Standards
UL E9809
Surface Finishing
Tin Plated
Temperature Range
105 °C
Voltage Rating
600 V
Data Sheet, Technical Information
RBB25
ETIM 7
EC001059 - Crimp splices for copper conductor
ETIM 8
EC001059 - Crimp splices for copper conductor
UNSPSC
39121449
WEEE Category
Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)
4669 >> Wire or cable compression splice
