ABB 7TBA050280R0027 Meter Socket Transformer - CSA 27716
Part Number: 7TBA050280R0027
Quick Summary
ABB 7TBA050280R0027 meter socket transformer delivers unwired power conversion for underground service applications. Engineers confront field wiring complexity and limited test options, which can slow installation and increase risk. This unit is certified to CSA 27716 for underground equipment and safety compliance, supporting reliable Canadian and North American deployments. With a 20 A current rating and 600 V rating, it meets common underground service specs, while its compact footprint—19-1/8 in high, 11-13/16 in wide—facilitates installation in tight spaces. The combination of test-switch provision, unwired design, and standard 13 jaw enhances service-utility readiness, while the Microlectric branding signals robust, field-proven performance for meter sockets and related power distribution components.
Product Information
Extended Description
7TBA050280R0027 ABB: Meter socket transformer rated 20 amperes 600 volts. Unwired unit with test switch provision. 13 jaw.
UPC
624871003498
Country of Origin
Canada (CA)
Selling Unit of Measure
each
Package Level 1 Units
1 EA
Package Level 1 Width
196.85 mm | 7.75 in
Package Level 1 Height
317.5 mm | 12.5 in
Package Level 1 Depth / Length
523.24 mm | 20.6 in
Application
For underground service only
Brand / Label
Microlectric
Current Rating
20 A
Effective Date
19961217
Number of Phases
1 Phase
Product Name
Parts and accessories
Product Type
Meter Sockets
Size
19-1/8 Inches Height x 11-13/16 Inches Width x 5-7/16 Inches Depth
Standards
CSA 27716
Voltage Rating
600 V
Data Sheet, Technical Information
CT113
UNSPSC
39121102
WEEE Category
Product Not in WEEE Scope
IDEA Granular Category Code (IGCC)
4326 >> Test Block Bypass Meter Sockets
Feature → Unwired meter socket transformer with test switch provision and 13 jaw configuration. Business Impact → Reduces on-site wiring steps and accelerates commissioning, lowering labor costs while preserving secure, code-compliant connections. Application → Ideal for underground service connections that leverage standard meter sockets and service equipment. Feature → Rated for 20 A and 600 V in a single-phase arrangement. Business Impact → Delivers reliable capacity for typical underground service loads and improves voltage stability on feeders. Application → Suitable for service entry and small distribution panels that require consistent performance under load. Feature → Compact dimensions: 19-1/8 inches height x 11-13/16 inches width x 5-7/16 inches depth with CSA 27716 compliance. Business Impact → Saves valuable enclosure space and simplifies layout planning in constrained installations. Application → Retrofit projects and new builds in compact electrical rooms or buried service enclosures. Feature → 13 jaw connection system and single-phase, 20 A design. Business Impact → Enhances connection reliability and reduces field termination time, supporting faster startup. Application → Underground service feeders and meter-socket interfaces in commercial or industrial facilities. Feature → Canadian origin and MicroElectric branding. Business Impact → Facilitates procurement and traceability within North American electrical supply chains. Application → Suitable for projects that specify CSA-aligned components and recognized labeling for field personnel. Industry context and practical insight → In underground utility work, unwired units with test switch provisions streamline commissioning while maintaining safety. This ABB model aligns with common industry practices for meter sockets, reducing risk during installation and enabling technicians to verify continuity quickly before energizing circuits.
