ABB EF1012 Control and Automation Board - IS2 Enclosures
Part Number: EF1012
Quick Summary
ABB EF1012 is a control and automation board enclosure designed for IS2 automation deployments. It addresses the common challenge of messy cable routing and crowded panels by integrating fixed cable entry flanges and modular mounting. Key certifications include CE conformity with RoHS compliance (RoHS Date 20250108) and REACH declarations, with IP55 cable-entry option. For your procurement and installation teams, the enclosure offers a robust Galvanized Steel sheet construction and pre-assembled mounting, delivering faster, compliant deployments. This makes it suitable for automation panels in manufacturing, process, and packaging lines, and supports efficient maintenance and future upgrades.
Product Information
Extended Description
EF1012 ABB: Fixed Cable entry flanges 1000x1000mm (HxD)
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Design
Blind
Accessory Type
4. Cable entry flanges
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B310
Material
Galvanized Steel sheet
Options Provided
3. Fixed cable entry flanges IP55
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
835 mm
Product Net Height
1000 mm
Product Net Depth / Length
1000 mm
Product Net Weight
11.280 kg
Reference Depth/Length
1000 mm
Reference Height
1400 mm | 1600 mm | 1800 mm | 2000 mm | 2200 mm
Reference Width
1000 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
11.280 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC000211 - Gland plate for enclosure/cabinet
ETIM 9
EC000211 - Gland plate for enclosure/cabinet
eClass
V11.1 : 27142421
Object Classification Code
U
Standards
See code for structure
Feature: Fixed cable entry flanges and IP55 option → Business Impact: enhances cable management and environmental protection for electrical gear → Application: IS2 enclosures for automation, reducing installation time and post-install adjustments. Feature: Galvanized steel sheet construction → Business Impact: improves durability and corrosion resistance in harsh factory environments → Application: control panels exposed to dust, moisture, or splash zones. Feature: Kit or pre-assembled mounting → Business Impact: accelerates site deployment and simplifies retrofit projects → Application: scalable installations across multiple lines with consistent mounting standards. Feature: Compatibility with IS2 Enclosures for Automation and Automation Board class → Business Impact: ensures seamless interoperability and reduces engineering substitutions → Application: standardized procurement and faster changeovers. Feature: Comprehensive compliance suite (CE, RoHS, REACH, WEEE) → Business Impact: simplifies audits and regulatory adherence → Application: enterprise-grade deployments with traceable documentation. Feature: Dimensions and weight (835 mm width, 1000 mm height, 1000 mm depth; 11.280 kg) → Business Impact: predictable handling and space planning → Application: fitment in restricted control rooms and cabinet arrays. Insight: ETIM and eClass classifications aid purchasing workflows, while detailed manuals (1STM604121R0006) support on-site installation and future upgrades.
Get a Quick Quote for a ABB EF1012
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB EF1012?
Enquire Now
FAQs
Yes, EF1012 is designed for IS2 enclosures for automation and offers both kit and pre-assembled mounting options. This flexibility supports rapid install, simplified field upgrades, and consistent panel configurations across multiple sites. The mounting approach helps installers avoid custom fabrication and reduces commissioning time.
EF1012 features a product width of 835 mm, height of 1000 mm, and depth of 1000 mm, with a net weight of 11.280 kg. These compact, predictable dimensions streamline layout planning, cabinet stacking, and logistics. The weight remains manageable for standard lifting devices, aiding safe installation in constrained manufacturing environments.
EF1012 is purpose-built for control and automation board applications within IS2 enclosure systems. Its galvanized steel construction, cable entry flanges, and pre-assembled mounting option support robust control cabinet performance in automated lines, improving reliability, serviceability, and uptime across production environments.
EF1012 carries CE conformity and RoHS compliance with the RoHS date 20250108, plus REACH declarations. It is designated as WEEE not in scope for disposal, and ETIM/ eClass classifications help with procurement. This certification set supports regulatory readiness, safer supply chains, and audit readiness for industrial deployments.
Maintenance benefits come from durable galvanized steel construction, modular mounting, and readily available manuals, which reduce service time and downtime. The enclosure’s compliance and standardized IS2 compatibility promote longer service intervals, lower replacement costs, and faster project ROI through predictable installation, easier upgrades, and streamlined procurement processes.
