ABB EF1062 Control Board - CE & RoHS Certified
Part Number: EF1062
Quick Summary
ABB EF1062 Control Board enables compact automation panels for IS2 enclosures. Engineers often struggle with integrating fixed cable entry flanges while preserving space and IP ratings. It delivers CE conformity, RoHS compliance, and IP55-rated protection for cable entries. Designed as a kit with pre-assembled mounting and galvanized steel construction, this solution reduces installation time and streamlines sourcing for system integrators and panel builders. For teams pursuing reliable, standards-aligned automation infrastructure, this board offers compatibility with IS2 enclosures and ETIM classification, supporting efficient project delivery and long-term maintenance. This aligns with IS2 catalogue expectations and the IS2 Enclosures Technical Catalogue 2024 references.
Product Information
Extended Description
EF1062 ABB: Fixed Cable entry flanges 1000x600mm (HxD)
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Design
Blind
Accessory Type
4. Cable entry flanges
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B310
Material
Galvanized Steel sheet
Options Provided
3. Fixed cable entry flanges IP55
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
430 mm
Product Net Height
8 mm
Product Net Depth / Length
823 mm
Product Net Weight
6.20 kg
Reference Depth/Length
600 mm
Reference Height
1400 mm | 1600 mm | 1800 mm | 2000 mm | 2200 mm
Reference Width
1000 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
6.200 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC000211 - Gland plate for enclosure/cabinet
ETIM 9
EC000211 - Gland plate for enclosure/cabinet
eClass
V11.1 : 27142421
Object Classification Code
U
Standards
See code for structure
Feature: Integrated fixed cable entry flanges kit designed for IS2 automation enclosures. Business Impact: Simplifies cable management and reduces on-site assembly time, improving panel reliability in demanding environments. Application: Ideal for IS2 enclosure systems in automation projects where space is constrained and cable routing must be predictable. Feature: Mounting type kit with pre-assembled option. Business Impact: Cuts field assembly steps and minimizes misalignment risk, accelerating time-to-volume production. Application: Common in control panels and automation boards in industrial settings. Feature: Galvanized steel construction. Business Impact: Delivers robust corrosion resistance and long service life in harsh environments, lowering maintenance costs. Application: Outdoor or humid plant floors where enclosure integrity matters. Feature: IP55-rated fixed cable entry flanges. Business Impact: Provides targeted ingress protection for cables, increasing uptime and safety. Application: Electrical cabinets handling multiple cables and glands. Feature: Compliance and documentation readiness (CE, RoHS, REACH) with ETIM classification. Business Impact: Facilitates procurement, reduces compliance risk, and speeds regulatory approvals. Application: Projects governed by strict standards and rapid commissioning.
Get a Quick Quote for a ABB EF1062
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB EF1062?
Enquire Now
FAQs
EF1062 is designed as a kit with mounting options that can be pre-assembled, simplifying installation in IS2 automation enclosures. It supports 4 cable entry flanges and IP55 protection, reducing field alignment issues and spare parts overhead. Installers benefit from clear references in the IS2 Enclosures Technical Catalogue 2024 and the provided manuals, which streamline commissioning and reliability checks.
Key dimensions include a product net width of 430 mm and net depth of 823 mm, with reference width 1000 mm and reference depth 600 mm. The kit uses galvanized steel and provides IP55-rated fixed cable entry flanges, offering robust ingress protection. Weight is approximately 6.20 kg, and the design supports a range of enclosure heights from 1400 mm to 2200 mm, aligning with IS2 catalog requirements.
EF1062 is ideal for control and automation boards within IS2 enclosures where space is constrained and cable routing must be neat and protected. Its pre-assembled mounting option speeds deployment in panel builders and system integrators, while its corrosion-resistant galvanized steel construction suits harsh manufacturing environments and outdoor or semi-outdoor installations.
EF1062 carries CE conformity and RoHS information with a RoHS date of 20250108 and a REACH declaration confirming no substances above 0.1 mass percentage. WEEE categorization indicates the product is not within WEEE scope. These certifications simplify regulatory approvals and procurement for compliant automation projects.
By combining a pre-assembled mounting kit with fixed cable entry flanges IP55, EF1062 reduces installation time and field errors, lowering labor costs and downtime. Its standardized dimensions and ETIM classification support faster sourcing and better supplier alignment, while CE and RoHS compliance minimize risk across regulated markets.
