ABB EF4012 Control and Automation Board - IP55
Part Number: EF4012
Quick Summary
ABB EF4012 Control and Automation Board enables integrated control in IS2 automation enclosures. It addresses installation delays caused by complex cable routing and space constraints by delivering a pre-assembled kit with fixed cable entry flanges. The solution carries CE conformity, RoHS information, and REACH declarations, ensuring compliance across regulated environments, while an IP55 option delivers improved sealing in tough industrial settings. Designed for IS2 enclosures in automation projects, it supports scalable layouts and fast integration, helping replace custom enclosures with a standardized, serviceable module. This combination of rugged galvanized steel construction, standard gland-plate compatibility, and a kit-based mounting approach lowers lifecycle costs and simplifies procurement for engineers and procurement teams.
Product Information
Extended Description
EF4012 ABB: Fixed Cable entry flanges 400x1000mm (HxD)
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Design
Blind
Accessory Type
4. Cable entry flanges
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B310
Material
Galvanized Steel sheet
Options Provided
3. Fixed cable entry flanges IP55
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
233 mm
Product Net Height
400 mm
Product Net Depth / Length
1000 mm
Product Net Weight
3.910 kg
Reference Depth/Length
1000 mm
Reference Height
1400 mm | 1600 mm | 1800 mm | 2000 mm | 2200 mm
Reference Width
400 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
3.910 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC000211 - Gland plate for enclosure/cabinet
ETIM 9
EC000211 - Gland plate for enclosure/cabinet
eClass
V11.1 : 27142421
Object Classification Code
U
Standards
See code for structure
Feature: Fixed cable entry flanges 400x1000 mm with IP55 sealing. Business impact: Simplifies cable routing, enhances enclosure integrity, reduces field rework, leading to faster installation and lower service costs. Application: IS2 Enclosures for Automation in harsh factory floors. Paragraph two highlights galvanized steel sheet construction for durability and corrosion resistance, reducing maintenance cycles in demanding environments. Paragraph three emphasizes mounting Type Kit | Pre assembled, enabling faster commissioning and consistent installation across projects. Paragraph four notes compact product net dimensions 233 mm width by 400 mm height and 1000 mm depth, with reference heights from 1400 to 2200 mm, ensuring IS2 compatibility and easy integration. Paragraph five covers regulatory compliance with CE, RoHS, and REACH declarations, paired with WEEE status and gland-plate compatibility to streamline procurement and audits.
Get a Quick Quote for a ABB EF4012
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB EF4012?
Enquire Now
FAQs
ABB EF4012 ships as a pre assembled kit for IS2 automation enclosures. Install by mounting the board in the enclosure using the included hardware, align with gland plate locations, and secure. The fixed cable entry flanges simplify cable routing and enable IP55 sealing, improving environmental protection. During commissioning, verify CE conformity and RoHS/REACH declarations to ensure regulatory compliance.
Key specs include a product net width of 233 mm, net height of 400 mm, and net depth of 1000 mm, with an approximate weight of 3.910 kg. The construction uses galvanized steel sheet, mounting as a Kit | Pre assembled, and fixed cable entry flanges with IP55 options. It is designed for IS2 Enclosures for Automation and supports gland plate compatibility with ETIM EC000211.
Yes. EF4012 provides fixed cable entry flanges with IP55 sealing to protect against dust and water ingress in demanding environments. It is built for IS2 automation enclosures and offers a streamlined approach to cable management, reducing field time and sealing adjustments while maintaining enclosure integrity in factory and process settings.
EF4012 carries a CE Declaration of Conformity, RoHS information, and a REACH declaration dated 20250108, supporting regulatory compliance in European installations. WEEE classification notes Product Not in WEEE Scope, and ETIM classifications EC000211 for gland plates align with standard cataloging. Together, these certifications streamline audits, procurement, and cross-system compatibility for automation projects.
Using EF4012 reduces field labor through its pre assembled mounting kit and standardized IP55 cable entry, while its galvanized steel construction offers longer service life. This combination lowers installation time, minimizes rework, and simplifies maintenance planning. For IS2 enclosure projects, EF4012 supports faster commissioning, reduced downtime, and improved total cost of ownership.
