ABB EF6012 Other/Miscellaneous Cable Flange Kit - IP55
Part Number: EF6012
Quick Summary
ABB EF6012 is a galvanized steel cable entry kit for IS2 automation enclosures. Engineers often struggle with modular cable routing and IP-rated seals in tight installations, risking downtime. It carries CE conformity for IS2, RoHS compliance since 2025-01-08, and a REACH declaration, supporting regulatory approvals. Designed to integrate with IS2 enclosures, this pre-assembled kit reduces field work and ensures consistent seal integrity. With IP55 protection and galvanized steel construction, it helps reduce maintenance costs while speeding up panel assembly for high-volume production. Adopt this solution to improve reliability in harsh industrial environments and streamline procurement through a single compatible accessory.
Product Information
Extended Description
EF6012 ABB: Fixed Cable entry flanges 600x1000mm (HxD)
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Design
Blind
Accessory Type
4. Cable entry flanges
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B310
Material
Galvanized Steel sheet
Options Provided
3. Fixed cable entry flanges IP55
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
433 mm
Product Net Height
600 mm
Product Net Depth / Length
1000 mm
Product Net Weight
5.860 kg
Reference Depth/Length
1000 mm
Reference Height
1400 mm | 1600 mm | 1800 mm | 2000 mm | 2200 mm
Reference Width
600 mm | 1200 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
5.860 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC000211 - Gland plate for enclosure/cabinet
ETIM 9
EC000211 - Gland plate for enclosure/cabinet
eClass
V11.1 : 27142421
Object Classification Code
U
Standards
See code for structure
Fixed cable entry flanges deliver a secure, weather-resistant entry path that minimizes ingress risks and seal leaks. This directly reduces field commissioning time and helps maintain enclosure integrity across changing cable routings. In automation panel builds, it translates to fewer gasket failures and lower maintenance costs. Four fixed cable entry flanges with IP55 offer a secure, weather-resistant entry path. That enhances system reliability by reducing ingress and seal failures, cutting maintenance and retrofit costs. Designed for IS2 automation enclosures in factory floors and outdoor plants. Pre-assembled mounting kit reduces on-site assembly time and eliminates misalignment from improvised fittings. This speeds up panel commissioning by minimizing field drilling and compatibility issues across IS2 enclosures. Galvanized steel sheet provides robust durability in harsh environments, lowering replacement frequency and total cost of ownership. For outdoor or humid environments, the protective coating maintains enclosure integrity while meeting industry standards. Compatibility with IS2 enclosures reduces procurement complexity and expedites upgrades. Compliance with RoHS and REACH declarations; CE conformity supports regulatory approvals, while WEEE classification clarifies end-of-life considerations. These investments translate to shorter lead times, fewer supplier coordination steps, and a lower total cost of ownership over the life of automation cabinets.
Get a Quick Quote for a ABB EF6012
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB EF6012?
Enquire Now
FAQs
Installation begins by aligning the pre-assembled kit with the IS2 enclosure openings, securing the four fixed cable entry flanges to achieve IP55 sealing. Clean mating surfaces, apply appropriate sealing gaskets, and tighten to recommended torque to avoid leaks. Verify CE conformity labeling and RoHS/REACH documentation during commissioning.
Yes, EF6012 is designed for IS2 Enclosures for Automation and comes as a pre-assembled mounting kit. This compatibility eliminates custom fabrication, reduces field assembly steps, and shortens installation time, particularly in high-volume panel builds where consistent sealing and fit are critical.
Key dimensions include 433 mm net width, 600 mm net height, and 1000 mm net depth. The package weight is 5.860 kg per unit. These metrics help plan mounting clearance, cable routing, and mounting hardware selections within IS2 enclosure layouts.
EF6012 carries CE conformity for IS2, RoHS compliance with a 20250108 RoHS date, and a REACH declaration. WEEE classification indicates product not in WEEE scope. ETIM and eClass references also align EF6012 for gland plate compatibility and industry-standard classification.
The IP55-rated flanges and galvanized steel construction reduce ingress-related maintenance, extending enclosure life and lowering retrofit costs. Pre-assembled installation cuts labor time and errors, accelerating commissioning. Across multiple panel builds, this translates to measurable reductions in downtime, faster upgrades, and a lower total cost of ownership.
