ABB EF8062 Control Board - IP55 Cable Entry Flanges
Part Number: EF8062
Quick Summary
ABB EF8062 Control Board is a rugged control solution for manufacturing automation enclosures. Engineers often struggle with mounting, cable entry management, and ensuring regulatory compliance during upgrades. This IS2-aligned solution supports CE conformity, RoHS compliance, and REACH declarations, while IP55-rated cable entries protect against dust and water ingress. For procurement teams, the modular kit approach reduces installation time, simplifies maintenance, and lowers total cost of ownership while meeting evolving automation needs.
Product Information
Extended Description
EF8062 ABB: Fixed Cable entry flanges 800x600mm (HxD)
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Design
Blind
Accessory Type
4. Cable entry flanges
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B310
Material
Galvanized Steel sheet
Options Provided
3. Fixed cable entry flanges IP55
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
430 mm
Product Net Height
8 mm
Product Net Depth / Length
625 mm
Product Net Weight
4.710 kg
Reference Depth/Length
600 mm
Reference Height
1400 mm | 1600 mm | 1800 mm | 2000 mm | 2200 mm
Reference Width
800 mm | 1600 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
4.710 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC000211 - Gland plate for enclosure/cabinet
ETIM 9
EC000211 - Gland plate for enclosure/cabinet
eClass
V11.1 : 27142421
Object Classification Code
U
Standards
See code for structure
IS2 Enclosures compatibility aligns with the ABB IS2 enclosure family, reducing engineering time and minimizing field rework during panel upgrades. The kit offers a pre-assembled mounting solution that speeds commissioning and ensures consistent assembly across multiple panels, cutting on-site labor and QA costs. Galvanized steel construction delivers robust durability in harsh industrial environments, extending service life and lowering replacement expenditures. IP55 fixed cable entry flanges enhance cable management and ingress protection, reducing EMC concerns and simplifying future upgrades. With precise dimensions and reference footprints (430 mm net width, 625 mm net depth, 1400–2200 mm heights, 800–1600 mm widths), installers can plan layouts accurately and integrate with IS2-based automation panels while meeting RoHS and REACH regulatory requirements.
Get a Quick Quote for a ABB EF8062
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB EF8062?
Enquire Now
FAQs
EF8062 is designed for IS2 Enclosures for Automation. It supports reference widths of 800 mm or 1600 mm and reference heights from 1400 to 2200 mm, with a net width of 430 mm and net depth of 625 mm. This alignment facilitates seamless integration in standard automation cabinets and reduces enclosure fit issues during upgrades.
Key specs include a net width of 430 mm, net depth of 625 mm, and a net height listed as 8 mm (part of the internal measurement stack). The reference footprint accommodates 800/1600 mm widths and 1400–2200 mm heights, with a shipping weight of 4.710 kg. The material is galvanized steel sheet, providing durable, robust performance in industrial settings.
Yes, the EF8062 features IP55-rated fixed cable entry flanges. The accessory configuration includes fixed cable entry flanges IP55, delivering reliable ingress protection for cable management and maintaining performance in dusty or damp environments commonly found in automation panels.
EF8062 carries CE conformity via the Declaration of Conformity IS2, RoHS information with a RoHS date of 20250108, and REACH declarations with a REACH date of 20250108. WEEE categorization indicates the product is not within WEEE scope. These certifications help streamline regulatory compliance in industrial deployments.
The mounting type is a kit or pre-assembled solution, which reduces on-site assembly time and errors. Paired with IS2 enclosure compatibility, it shortens commissioning, improves repeatability across multiple panels, and lowers labor costs. Regulatory compliance support further reduces risk and potential rework, contributing to a lower total cost of ownership over the equipment lifecycle.
