ABB EG2200 Control & Automation Board - 19\" rack structure
Part Number: EG2200
Quick Summary
ABB EG2200 Control & Automation Board enables reliable 19‑inch mounting for IS2 automation enclosures, ideal for scalable control cabinets. Engineers often struggle with modularity and compatibility when upgrading frames or adding new modules, leading to downtime and misfits. This solution features a CE Declaration of Conformity, RoHS compliance, and ETIM classification, ensuring alignment with standard enclosure architectures. With pre-assembled mounting and galvanised steel construction, it reduces installation time while delivering robust mechanical integrity. The result is higher system uptime, lower lifecycle costs, and easier maintenance across automation projects.
Product Information
Extended Description
EG2200 ABB: Fixed rack frame 2200x600mm fisso 47HE
Sub-Function 3
482.6 mm (19 inch) mounting set
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Accessory Type
13. 19" rack structure
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B350
Material
Galvanized Steel sheet
Options Provided
1. "L" shaped uprights for fixed frame
Remarks
ETIM
RoHS Information
1STC860065
RoHS Date
20140108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
40 mm
Product Net Height
2200 mm
Product Net Depth / Length
30 mm
Product Net Weight
4.050 kg
Reference Depth/Length
300 mm | 400 mm | 500 mm | 600 mm | 800 mm | 1000 mm
Reference Height
2200 mm
Reference Width
600 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
4.130 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC002625 - Mounting accessories (enclosure/cabinet)
ETIM 9
EC002625 - Mounting accessories (enclosure/cabinet)
eClass
V11.1 : 27182807
Object Classification Code
U
Standards
See code for structure
