ABB EL1840K Side Panels - RoHS 20250108
Part Number: EL1840K
Quick Summary
ABB EL1840K Side Panels are rugged, pre-fabricated blinds for 1800 mm control cabinets in automation environments. They reduce on-site modification and installation downtime by arriving kit-ready or fully assembled. The product carries CE conformity, RoHS compliance dated 20250108, and REACH declarations for regulatory readiness and environmental responsibility. Built for IS2 enclosure systems, these panels feature pickled steel with orange-peel finish in RAL 7035, delivering durable protection and consistent aesthetics. Compatibility with ETIM 8 EC002524 classifications and eClass 27182101 helps streamline procurement and asset data management. This combination supports faster project timelines and lower total cost of ownership.
Product Information
Extended Description
EL1840K ABB: Pair of blind side panels 1800x400mm (HxW)
Sub-Function 3
Side panel
Accessory Type
1. Side panels
Mounting Type
Kit | Pre assembled
Product Type
5B5B20B250
Surface Finishing
Orange Peel, RAL 7035
Material
Pickled steel sheet
Options Provided
No. 2 blind side panles
Remarks
ETIM
RAL Number
RAL 7035 - Light Grey
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
394 mm
Product Net Height
1796 mm
Product Net Depth / Length
16 mm
Product Net Weight
18.240 kg
Reference Depth/Length
400 mm
Reference Height
1800 mm
Reference Width
400 mm | 600 mm | 800 mm | 1000 mm | 1200 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
18.620 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC002524 - Side-/back panel (enclosure/cabinet)
ETIM 9
EC002524 - Side-/back panel (enclosure/cabinet)
eClass
V11.1 : 27182101
Object Classification Code
U
Standards
See code for structure
Feature mounting type is Kit or Pre assembled, enabling rapid installation and reduced field labor compared with custom fabrication. Business impact includes faster project readiness and tighter dimensional control, which minimizes rework in automation cabinet projects. Application: IS2 enclosure systems demanding reliable side coverage with precise fit. Feature material is pickled steel sheet with orange-peel surface in RAL 7035, delivering robust mechanical protection and a clean industrial appearance, lowering maintenance costs over the cabinet life. Feature surface finishing and coating improve corrosion resistance in harsh plant environments, translating to longer service intervals and fewer replacements. Feature dimensions include 394 mm net width, 1796 mm net height, and 16 mm depth, ensuring consistent enclosure geometry across standard configurations and simplifying design verification. Feature regulatory and data standards include RoHS, REACH, CE declarations, and ETIM/eClass classifications to streamline purchasing, part tagging, and data integration for maintenance planning. Feature packaging indicates one piece per package with a total weight of 18.24 kg, aiding logistics and inventory control in regional warehouses.
Get a Quick Quote for a ABB EL1840K
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB EL1840K?
Enquire Now
FAQs
Yes, these panels are designed for IS2 enclosure systems and offer Kit or Pre assembled mounting options, enabling rapid integration with standard enclosure frames and reducing on-site fabrication time.
Key specs include a net width of 394 mm, net height of 1796 mm, net depth of 16 mm, weight 18.24 kg, material is pickled steel sheet, and finishing is orange peel in RAL 7035.
Yes. The panels use durable pickled steel with an orange-peel finish and RoHS/REACH compliance, making them suitable for industrial automation cabinets, with IS2 enclosure compatibility and robust mechanical protection.
They include CE Declaration of Conformity, RoHS information with date 20250108, REACH declaration with 20250108 date, and WEEE category indicating non-scope, aiding regulatory readiness.
Pre-assembled or kit options reduce field labor and misalignment risk, while a durable steel build and standardised dimensions improve maintenance predictability and asset data management, delivering lower total cost of ownership over the cabinet lifecycle.
