ABB ER3011K Control and Automation Board - CE
Part Number: ER3011K
Quick Summary
ABB ER3011K is a control and automation board designed for IS2 enclosures in industrial automation installations. This solution addresses the common challenge of integrating external cable management without compromising serviceability or protection. It carries CE conformity (IS2) and RoHS/REACH compliance to support safe, regulation-ready deployments in modern plants. With flexible mounting options—kit or pre-assembled—the ER3011K delivers consistent compatibility across ABB IS2 systems while reducing on-site wiring effort. In practice, this translates to shorter installation times, fewer field modifications, and improved traceability for routine maintenance and audits.
Product Information
Extended Description
ER3011K ABB: Container for external cable container 2000x300x1000mm (WxD)
Sub-Function 3
Cable trough
Suitable For
IS2 Enclosures for Automation
Suitable for Product Class
Control and Automation Board
Accessory Type
10. Cable container
Mounting Type
Kit | Pre assembled
Product Type
5B5B30B392
Surface Finishing
Orange Peel, RAL 7035
Material
Pickled steel sheet
Options Provided
1. Container for external cable connection W=300mm
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
300 mm
Product Net Height
2000 mm
Product Net Depth / Length
1.000 mm
Product Net Weight
40.4250 kg
Reference Depth/Length
1000 mm
Reference Height
2000 mm
Reference Width
400 mm | 600 mm | 800 mm | 1000 mm | 1200 mm | 1600 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
41.425 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
1STM604121R0006
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC002620 - Components for installation (enclosure/cabinet)
ETIM 9
EC002620 - Components for installation (enclosure/cabinet)
eClass
V11.1 : 27182811
Object Classification Code
U
Standards
See code for structure
Material and finish combine with robust enclosure compatibility to deliver corrosion resistance and a professional, touch-safe surface. Pickled steel sheet with Orange Peel finish (RAL 7035) ensures long-term protection in harsh industrial environments, reducing refurbishment costs and downtime due to weathering. The 300 mm net width, 2,000 mm net height, and 1,000 mm net depth align with standard IS2 enclosure footprints, enabling rapid configuration across varied panel widths. Mounting type supports both kit and pre-assembled options, lowering labor costs and enabling faster commissioning while preserving field serviceability for future upgrades. The included 10. Cable container accessory streamlines external connection management, minimizing cable clutter and facilitating easier fault tracing during maintenance windows. RoHS and REACH declarations, paired with a CE conformity certificate, reduce regulatory risk and support compliance-driven procurement across global sites. Designed for IS2 Enclosures for Automation, ER3011K delivers predictable performance, easier audits, and scalable wiring for multi-panel automation projects.
Get a Quick Quote for a ABB ER3011K
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB ER3011K?
Enquire Now
FAQs
ER3011K is designed to be compatible with IS2 Enclosures for Automation. It offers mounting options as a kit or pre-assembled unit, allows handling within standard 300 mm width variants, and aligns with IS2 installation practices to minimize site tailoring and maximize reliability.
Key specs include Product Net Width 300 mm, Product Net Height 2000 mm, Product Net Depth 1000 mm, and a Net Weight of 40.425 kg. It features Pickled steel sheet material, Orange Peel surface finishing in RAL 7035, and supports a 1 piece package with a 41.425 kg packaged weight.
Yes. The ER3011K carries a Declaration of Conformity CE for IS2, and complies with RoHS and REACH requirements. It also notes REACH information and dates, ensuring regulatory alignment for global deployments and responsible material usage.
The 10. Cable container accessory provides dedicated space for external cable connections, reducing cable clutter and improving fault tracing. Its kit or pre-assembled options speed up installation, while the enclosure compatibility and compliant materials simplify routine maintenance and audits across automation panels.
Using ER3011K standardizes external cable management, shortens commissioning times, and reduces on-site labor. Its regulatory compliance minimizes risk and rework, while durable materials and compatible mounting options lower lifecycle costs and enable scalable wiring across multi-panel systems.
