ABB ZU1101 Control Board Enclosure - IS2 System pro E
Part Number: ZU1101
Quick Summary
ABB ZU1101 control board enclosure enables compact automation control within System pro E IS2 cabinets. Engineers often struggle with integration, space constraints, and maintaining consistent panel layouts during upgrades. This enclosure aligns with CE Declaration of Conformity, RoHS compliance, and REACH requirements, while ETIM and eClass classifications support accurate part matching. Built for automation and control applications, it delivers scalable kit options and pre-assembled configurations that reduce on-site complexity and help shorten project timelines, ultimately lowering total cost of ownership for panel builds and retrofit programs.
Product Information
Extended Description
ZU1101 ABB: Entire Striph=100xswitc.Bat.Um=M Mounted
Sub-Function 3
Base front/back
Suitable For
Automation and Control Enclosures (System pro E control) - IS2
Suitable for Product Class
Automation and Control Enclosures (System pro E control)
Accessory Type
7. Plinth
Mounting Type
Kit | Pre assembled
Product Type
5B5B35B335
Material
Pickled steel sheet
Options Provided
Single plinth (unit of measure for the order: METRE)
Remarks
ETIM
RoHS Information
RoHS information
RoHS Date
20250108
REACH Declaration
REACH declaration
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20250108
WEEE Category
Product Not in WEEE Scope
Environmental Information
IS2 Enclosures Technical Catalogue 2024
Product Net Width
800 mm
Product Net Height
100 mm
Product Net Depth / Length
1000 mm
Product Net Weight
8.351 kg
Reference Depth/Length
300 mm | 400 mm | 500 mm | 600 mm | 800 mm | 1000 mm
Reference Height
1400 mm | 1600 mm | 1800 mm | 2000 mm | 2200 mm
Reference Width
400 mm | 600 mm | 800 mm | 1000 mm | 1200 mm
Package Level 1 Units
1 piece
Package Level 1 Gross Weight
8,351 kg
Declaration of Conformity - CE
Declaration of Conformity IS2
Instructions and Manuals
IS2 instruction handbook 2024
Data Sheet, Technical Information
IS2 Enclosures Technical Catalogue 2024
ETIM 8
EC000721 - Base/base element (enclosure/cabinet)
ETIM 9
EC000721 - Base/base element (enclosure/cabinet)
eClass
V11.1 : 27182003
Object Classification Code
U
Standards
See code for structure
Feature: System pro E IS2 compatibility and pre-assembled kit options → Business Impact: Reduces integration time, ensures regulatory alignment, and lowers field wiring errors → Application: Panel upgrades in automation and control cabinets where System pro E control is deployed. Feature: Base front/back and modular plinth mounting → Business Impact: Simple installation with robust support and fewer misalignments → Application: Industrial control panels requiring stable base alignment and easy service access. Feature: Pickled steel sheet construction → Business Impact: Enhanced durability in harsh environments with predictable corrosion performance → Application: Factory automation enclosures and machine control houses. Feature: Flexible reference depth/height/width options → Business Impact: Configurable footprints that fit existing rack spaces and procurement budgets → Application: Custom panel layouts in IS2 enclosure families. Feature: Pre assembled line items and single plinth options → Business Impact: Faster deployment, reduced commissioning time, and lower skilled labor requirements → Application: Large-scale installations and retrofit projects where speed matters. Feature: Comprehensive compliance (RoHS, REACH, WEEE) → Business Impact: Lower regulatory risk and smoother procurement cycles → Application: Enclosures for regulated spaces and global manufacturing deployments.
Get a Quick Quote for a ABB ZU1101
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB ZU1101?
Enquire Now
FAQs
ABB ZU1101 is designed to integrate with System pro E control IS2 enclosures. It supports pre-assembled mounting kits and base/front-back mounting, enabling quick alignment with IS2 cabinet templates. For best results, verify reference dimensions (width 800 mm, depth 1000 mm, height options 1400–2200 mm) during planning and order the corresponding plinth length as a metre unit.
The enclosure features a product net width of 800 mm, height of 100 mm, and depth of 1000 mm, with reference dimensions spanning width 400–1200 mm and height 1400–2200 mm. Depth references range from 300–1000 mm. This allows flexible configuration to fit existing panels while maintaining service access and cable routing.
The ZU1101 supports CE Declaration of Conformity, RoHS information with a RoHS date of 20250108, and REACH declaration with REACH date 20250108. It is classified under WEEE as not in scope and aligns with ETIM EC000721 and eClass 27182003 for standardized parts matching and procurement workflows.
The kit/Pre assembled mounting approach reduces field assembly steps, limits alignment errors, and speeds up commissioning. By delivering components in a ready-to-install format, project teams realize shorter installation windows, lower labor costs, and improved repeatability across multiple enclosure builds in automation projects.
This enclosure is ideal for automation and control cabinets in System pro E control environments, including factory automation, packaging lines, and process control rooms. Its durable pickled steel construction, IS2 compatibility, and flexible reference options support scalable panel architectures while maintaining regulatory compliance and long-term maintenance ease.
