Eaton 12191020104 EXIT Sign - IP66
Part Number: 12191020104
Quick Summary
EXIT Sign from Eaton's Crouse-Hinds series provides reliable emergency illumination and clear egress signaling for hazardous industrial spaces. In demanding environments, standard signs fail under dust, moisture, or explosive atmospheres, delaying safe evacuation. It carries IECEx/ATEX certifications for Zone 1, Zone 21, Zone 2, and Zone 22, and an IP66 ingress rating, ensuring safe operation in harsh locations. LED technology reduces energy use and maintenance while the gray polycarbonate housing withstands demanding environments. The unit's wall or ceiling mounting options, plus the included monitoring module and cover, streamline installation and help facilities maintain compliance with safety codes and plant-wide reliability.
Product Information
Extended Description
12191020104 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EXIT Clear V-CG-S exit sign, 50-60 Hz, Gray, LED, 166 lumens, Polycarbonate, Wall/ceiling mount, Includes cover, monitoring module, 2 x M20 metal thread, 220-254 Vac, 195-250 Vdc
Product Name
Eaton's Crouse-Hinds series EXIT Clear V-CG-S exit sign
Catalog Number
12191020104
Product Length/Depth
380.5 mm
Product Height
175 mm
Product Width
76 mm
Product Weight
2.2 kg
EAN
4250217412936
Area classification
Hazardous/Classified Locations
Standards type
IECEx/ATEX IEC
IECEx/ATEX hazardous rating
Zone 2 Zone 22 Zone 1 Zone 21
Ingress protection (IP) ratings
IP66
Lamp type
LED
Trade size
2 x M20 metal thread
Special features
Includes cover, monitoring module
Voltage rating
220-254 Vac, 195-250 Vdc
Frequency rating
50-60 Hz
Material
Polycarbonate
Housing finish color
Gray
Lumens
166
Mounting
Wall/ceiling
LED lamp delivers 166 lumens with low power consumption, reducing energy costs and extending LED life to minimize maintenance and downtime in hazardous environments such as chemical plants and refineries. The IP66 enclosure and IECEx/ATEX certification provide rugged reliability in dust, water exposure, and explosive atmospheres, supporting compliance across Zone 1/21 and Zone 2/22 locations. The unit supports 220-254 Vac and 195-250 Vdc at 50-60 Hz, enabling straightforward integration with existing power systems and reducing wiring complexity. Included cover and monitoring module enhance field reliability by enabling status reporting and faster fault resolution. With 2 x M20 metal-thread entries and a durable polycarbonate housing, installation is robust for retrofit projects and new builds alike.
Get a Quick Quote for a Eaton Crouse-Hinds 12191020104
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 12191020104?
Enquire Now
FAQs
12191020104 EXIT Sign supports wall and ceiling mounting for flexible placement in hazardous locations. It offers two M20 metal-thread entries for secure conduit connections, a protective cover, and a monitoring module for status signaling. Combined with IP66 and IECEx/ATEX ratings, this configuration enables compliant retrofit and new installs in Zone 1/21 and Zone 2/22 without special enclosure.
The sign carries IECEx/ATEX certifications for hazardous locations, covering Zone 1 and Zone 21 as well as Zone 2 and Zone 22. This approval supports safe operation in explosive atmospheres found in chemical plants, oil and gas facilities, and other classified locations, reducing procurement risk and simplifying regulatory audits.
Yes. The unit supports a wide voltage range of 220-254 Vac and 195-250 Vdc with a 50-60 Hz supply, enabling direct integration into most industrial power distributions. The 2 x M20 entries provide robust wiring capability, and the LED design offers long life with minimal commissioning requirements.
The included monitoring module provides real-time status feedback and fault reporting, enabling proactive maintenance and reducing mean time to repair. This leads to less unplanned downtime, improved safety compliance, and longer service intervals, delivering measurable ROI through lower maintenance labor costs and higher plant availability.
LED exit signs like 12191020104 require minimal routine upkeep. Regular cleaning to remove dust and periodic checks of mounting security are typically sufficient. The LED lifespan and IP66 enclosure minimize component replacements, while IECEx/ATEX compliance ensures continued performance in hazardous areas. Schedule periodic tests to verify monitoring module reporting and illumination.
