Eaton Crouse-Hinds 12191030102 Exit Sign - IECEx/ATEX Zone 1
Part Number: 12191030102
Quick Summary
Eaton Crouse-Hinds EXIT N exit sign provides reliable emergency illumination for hazardous-area facilities. In challenging environments, signs can fail under moisture, dust, or explosive atmospheres, causing downtime and safety risks. This model carries IECEx/ATEX certification for Zone 1 and Zone 21, plus IP66 ingress protection and DIN 4844 mounting compatibility, ensuring compliance and straightforward installation. With a self-contained battery system and a wide input range of 110–277 VAC or 110–250 VDC, it supports wall-mount installation and long service life. The LED design delivers clear, readable signage with white letters on a gray housing, delivering value across manufacturing, chemical processing, and energy facilities.
Product Information
Extended Description
12191030102 Eaton Crouse-Hinds: Eaton Crouse-Hinds series EXIT N exit sign, Arrowhead left, Gray, LED, White letter color, Polycarbonate, Wall mount, Cover with silk-screen pictogram (arrow 9h), battery, 2 x M20 metal thread, DIN 4844, 110-277 Vac, 110-250 Vdc
Product Name
Eaton's Crouse-Hinds series EXIT N exit sign
Catalog Number
12191030102
Product Length/Depth
380.5 mm
Product Height
175 mm
Product Width
76 mm
Product Weight
2.1 kg
EAN
4250217412769
Area classification
Hazardous/Classified Locations
Standards type
IEC IECEx/ATEX
IECEx/ATEX hazardous rating
Zone 21 Zone 1
Ingress protection (IP) ratings
IP66
Lamp type
LED
Exit sign designation
Arrowhead left
Type
DIN 4844
Trade size
2 x M20 metal thread
Special features
Includes cover with silk-screen pictogram (arrow 9h), self-contained battery system
Voltage rating
110-277 Vac, 110-250 Vdc
Frequency rating
50-60 Hz
Letter color
White
Material
Polycarbonate
Housing finish color
Gray
Mounting
Wall
Crouse-Hinds series CEAG EXIT/EXIT2 Nonmetallic LED Exit Signs catalog page
Crouse-Hinds series CEAG EXIT N Nonmetallic LED Exit Signs operating instructions
LED illumination delivers high visibility with low power consumption, lowering energy costs and reducing heat generation in harsh environments. The long-life LED system minimizes maintenance cycles, improving facility uptime and lowering total cost of ownership for hazardous-location signage. The self-contained battery ensures operation during mains outages, providing continuous safety messaging even in power loss scenarios. A robust polycarbonate housing and IP66-rated enclosure protect against dust, water, and corrosive atmospheres, translating to fewer field service calls and more reliable signage. Wall-mount installation with DIN 4844 compatibility simplifies retrofits and new builds alike, while the 2 x M20 metal threads offer flexible cabling options for complex plant layouts. The unit’s wide voltage range—110–277 VAC or 110–250 VDC—supports diverse electrical infrastructures, enabling smooth cross-site deployments. Includes cover with silk-screen pictogram (arrow 9h) for immediate readability and a self-contained battery system that eliminates external power packs, reducing installation time and points of failure. This combination of features aligns with industry expectations for safety signage in chemical plants, refineries, and other classified locations, ensuring compliance and operational efficiency.
Get a Quick Quote for a Eaton Crouse-Hinds 12191030102
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in Eaton Crouse-Hinds 12191030102?
Enquire Now
FAQs
The EXIT N sign is designed for wall mounting with DIN 4844 compatibility and 2 x M20 metal threads for flexible cabling options. Its rugged polycarbonate housing, combined with IP66 protection, makes it suitable for hazardous locations. Mounting can be performed in a single-day retrofit or as part of new installations in process plants, refineries, and other classified areas, simplifying compliance and reducing downtime.
Yes. It carries IECEx/ATEX certifications for Zone 1 and Zone 21 hazardous locations, providing formal approval for operation in potentially explosive atmospheres. The unit also has IP66 ingress protection, ensuring protection against dust and powerful jets of water, which underpins reliable operation in challenging industrial environments.
The EXIT N exit sign supports a wide voltage range of 110–277 VAC or 110–250 VDC and operates at 50–60 Hz. It uses a self-contained battery system, enabling continued function during mains outages. This design minimizes external components, reduces installation complexity, and lowers maintenance overhead while guaranteeing visibility during power loss.
This LED exit sign is ideal for chemical plants, oil and gas facilities, and other workplaces with classified locations. Benefits include durable IP66 protection against dust and water, certified hazardous-location compliance, and long life with low maintenance. Its wall-mount capability and hidden wiring through M20 entries simplify retrofits and upgrades across multiple sites, delivering consistent safety messaging where it matters most.
The LED-based EXIT N sign delivers extended service life and lower energy consumption compared with traditional lighting sources, translating into reduced operating costs and fewer maintenance calls. Its self-contained battery eliminates the need for external power packs, decreasing installation time and potential failure points, while IECEx/ATEX and IP66 compliance minimizes regulatory risk and downtime in hazardous locations.
